Denon AVR-1509 Service Manual

116
AVR-1709/1609/1519/1509/689/589, AVC-1509
C753SR 00D9630223708 C,CERAMIC 270PF-J/50V E3 D010271167160S
C753SR 00D2570507950 CC73CH1H271JT +1608 E2,E1C,EA,JP -
C753SW 00D9630224008 C,CERAMIC 470PF-J/50V E3 D010471167160S
C753SW 00D2570508917 CC73CH1H471JT +1608 E2,E1C,EA,JP
C755C nsp C,CERAMIC 0.1UF-Z/50V E3
D011104597160S
C755FL nsp C,CERAMIC 0.1UF-Z/50V E3 D011104597160S
C755FR nsp C,CERAMIC 0.1UF-Z/50V E3 D011104597160S
C755SBL nsp C,CERAMIC 0.1UF-Z/50V E3 D011104597160S
C755SBR nsp C,CERAMIC 0.1UF-Z/50V E3 D011104597160S
C755SL nsp C,CERAMIC 0.1UF-Z/50V E3 D011104597160S
C755SR nsp C,CERAMIC 0.1UF-Z/50V E3 D011104597160S
C755SW nsp C,CERAMIC 0.1UF-Z/50V E3 D011104597160S
C756C 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C756FL 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C756FR 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SBL 00D9639003194 C,FILM 0.0022UF-J/100V AVR1709, 689 D02022206C060S
C756SBR 00D9639003194 C,FILM 0.0022UF-J/100V AVR1709, 689 D02022206C060S
C756SL 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SR 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SW 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C757C 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C757FL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C757FR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C757SBL 00D9630234205 C,ELECT 10UF-M/50V AVR1709, 689 D040100087070S
C757SBR 00D9630234205 C,ELECT 10UF-M/50V AVR1709, 689 D040100087070S
C757SL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C757SR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C757SW 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C901,902 nsp C,CERAMIC 0.1UF-Z/50V AVR589E3 D011104597160S
C903 00D9630234205 C,ELECT 10UF-M/50V AVR589E3 D040100087070S
C905 00D9630234205 C,ELECT 10UF-M/50V AVR589E3 D040100087070S
C906,907 00D9609009814 C,CERAMIC 330PF-J/50V AVR589E3 D010331167160S
C909,910 00D9630234205 C,ELECT 10UF-M/50V AVR589E3 D040100087070S
C911 00D9609010010 C,ELECT 4.7UF-M/50V AVR589E3 D0404R7087250S
C912 nsp C,CERAMIC 1000PF-K/50V AVR589E3 D011102777160S
C913 nsp C,CERAMIC 100PF-J/50V AVR589E3 D010101167160S
C918 nsp C,CERAMIC 100PF-J/50V AVR589E3 D010101167160S
C919,920 00D9630234205 C,ELECT 10UF-M/50V AVR589E3 D040100087070S
C927 nsp C,CERAMIC 0.1UF-Z/50V AVR589E3 D011104597160S
C941D 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
OTHERS PARTS GROUP
BD901,902 nsp COIL,BEAD MB-160808 AVR589E3
D340160800060S
BKT901 nsp BRACKET SN-P 0.5t/TUNER 4010212646000S
CN902 nsp CN.HOUSING 12P L120912120010S
CP109 nsp CN.WAFER 15P L101100031510S
CP110 nsp CN.WAFER 5P L101100030510S
JACK901 00D9630333601 MINI DIN CONNECTOR 8P
YKF51-5397N
E3 G403515397000S
TP803 nsp CN.WAFER 15P L101200101510S
Ref. No. Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
