Denon AVR-1509 Service Manual

29
AVR-1709/1609/1519/1509/689/589, AVC-1509
※ Unless specified, VIDEO UNIT part.
C
Input
CVBS/S
Check ± 5V, M_+5V.
+5V : CP514-2pin
-5V : CP514-3pin
M_+5V : CN1002-9pin
NG
To troubleshooting 1.1 Power not turn
on.
OK
Check output of AMP
Output V : IC1020-33pin
Output Y : IC1020-31pin
Output C : IC1020-29pin
NG
Check input of input selector and
surrounding circuitry soldering.
Input : IC1001,IV1007
OK
Check cable between main unit
and monitor or Check monitor.
※ 特に記載がない場合は VIDEO基板の部品です。
C
入力
CVBS/S
± 5V,M+5Vの確認
+5V:CP514-2pin
-5V:CP514-3pin
M+5V:CN1002-9pin
NG
1.1 電源が入らないのﾄﾗﾌﾞﾙｼｭｰﾃｨﾝｸﾞへ
OK
出力段 AMP の出力確認
出力 V:IC1020-33pin
出力 Y:IC1020-31pin
出力 C:IC1020-29pin
NG
入力ｾﾚｸﾀ及びその周辺回路の
ﾊﾝﾀﾞ付け確認
入力ｾﾚｸﾀ :IC1001,IC1007
OK
本体 -MONITOR間のｹｰﾌﾞﾙ
もしくはMONITOR 確認
