Denon AVR-1509 Service Manual

31
AVR-1709/1609/1519/1509/689/589, AVC-1509
※ Unless specified, VIDEO UNIT part.
D
Input
CVBS/S
Check +5, MC_+5V
+5V : IC1304-out pin
+9V : IC1307-out pin
MC_+5V : CN1002-9pin
NG
To troubleshooting 1.1
Power not turn on.
OK
Check output of input selector
Output V : C1301-1pin
Output Y : C1302-1pin
Output C : C1303-1pin
NG
Check input of input selector and
surrounding circuitry soldering.
or CPU B'D flaw
OK
Check output of buffer circuitry
Output V : C1343 +side
Output Y : C1345 +side
Output C : C1344 +side
NG
Check soldering of surrounding
buffer circuitry.
Output V : Q1305 surrounding
Output Y : Q1307 surrounding
Output C : Q1306 surrounding
OK
Check cable between main unit
and monitor or Check monitor.
E
Input
COMPONENT
Check +5, MC_+5V
+5V : IC1304-out pin
+9V : IC1307-out pin
MC_+5V : CN1002-9pin
NG
To troubleshooting 1.1
Power not turn on.
OK
Check output of input selector
Output Y : C1310 +side
Output Cb : C1316 +side
Output Cr : C1315- +side
NG
Check input of input selector and
surrounding circuitry soldering.
or CPU B'D flaw
OK
Check cable between main unit
and monitor or Check monitor.
※ 特に記載がない場合は VIDEO基板の部品です。
D
入力
CVBS/S
+5V,MC+5V の確認
+5V:IC1304-outpin
+9V:IC1307-outpin
MC+5V:CN1002-9pin
NG
1.1 電源が入らないのﾄﾗﾌﾞﾙｼｭｰﾃｨﾝｸﾞへ
OK
入力ｾﾚｸﾀの出力確認
出力 V:C1301-1pin
出力 Y:C1302-1pin
出力 C:C1303-1pin
NG
入力ｾﾚｸﾀ及びその周辺回路の
ﾊﾝﾀﾞ付け確認
もしくは
CPUB'D の不具合
OK
ﾊﾞｯﾌｧ回路出力確認
出力 V：C1343+ 側
出力 Y：C1345+ 側
出力 C：C1344+ 側
NG
ﾊﾞｯﾌｧ回路周辺のﾊﾝﾀﾞ付け確認
出力 V：Q1305周辺
出力 Y：Q1307周辺
出力 C：Q1306周辺
OK
本体 -MONITOR間のｹｰﾌﾞﾙ
もしくはMONITOR 確認
E
入力
COMPONENT
+5V,MC+5V の確認
+5V:IC1304-outpin
+9V:IC1307-outpin
MC+5V:CN1002-9pin
NG
1.1 電源が入らないのﾄﾗﾌﾞﾙｼｭｰﾃｨﾝｸﾞへ
OK
入力ｾﾚｸﾀの出力確認
出力 Y:C1310+ 側
出力 Cb:C1316+ 側
出力 Cr:C1315+ 側
NG
入力ｾﾚｸﾀ及びその周辺回路の
ﾊﾝﾀﾞ付け確認
もしくは
CPUB'D の不具合
OK
本体 -MONITOR間のｹｰﾌﾞﾙ
もしくはMONITOR 確認
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1509 Specifications

General

Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Number of Channels	5.1
HDMI Inputs	2
HDMI Outputs	1
Response Bandwidth	10Hz-100kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
Output Impedance / Channel	8 ohms
Frequency Response	10Hz-100kHz
Digital Audio Inputs	2 Optical, 1 Coaxial
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS, DTS Neo:6
Surround Sound Effects	Virtual Surround
Audio D/A Converter	192kHz/24-bit
Output Power / Channel	75 W
Tuner Frequency Range	FM: 87.5-108 MHz, AM: 522-1611 kHz
Video Inputs/Outputs	Component video input (2), Component video output (1), Composite video input (4), Composite video output (2)
Analog Audio Inputs/Outputs	4 Analog Audio Inputs, 1 Analog Audio Output
