87
AVR-1709/1609/1519/1509/689/589, AVC-1509
C224L 00D9630234205 C,ELECT 10UF-M/50V AVR1709
D040100087070S
C224R 00D9630234205 C,ELECT 10UF-M/50V AVR1709
D040100087070S
C231 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) AVR1709, 689
D040R10087080S
C232 nsp C,CERAMIC 0.01UF-K/50V AVR1709, 689
D010103777160S
C233 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) AVR1709, 689
D040010087150S
C234 nsp C,CERAMIC 100PF-J/50V AVR1709, 689
D010101167160S
C235,236 00D9609008653 C,FILM 0.012UF-J/100V AVR1709, 689
D02012306C060S
C237 00D9639005862 C,ELECT 47UF-M/16V AVR1709, 689
D040470083080S
C238-241 00D9630234205 C,ELECT 10UF-M/50V AVC1509
D040100087070S
OTHERS PARTS GROUP
CLAMP101 nsp CLAMP WIRE(SOLDER)
4330000120000S
CN101 nsp CN,WIRE 10P
L000111100070S
CN103 nsp CN,WIRE 7P
L000121070061S
CN201 nsp CN,WIRE 6P AVR1709, 689
L000700060111S
CN511 nsp CN,WIRE 9P
L000600090021S
CN704 nsp CN.WAFER 15P
L101100041510S
CP103 nsp CN.WAFER 3P AVR1709, 689
L102526700300S
CP104 nsp CN.WAFER 3CKT
L108353280360S
CP105 nsp CN.WAFER 7P
L101100040710S
CP106 nsp CN.WAFER 5P
L101100040510S
CP107 nsp CN.WAFER 3P
L102526700300S
CP108 nsp CN.WAFER 18P
L101100041810S
CP109 nsp CN.WAFER 5P
L101100040510S
CP541 nsp CN.WAFER 3P
L101200100310S
GND101 nsp TERMINAL EARTH
3790040886000S
JACK221 90M-YT004640R MODULE JSR1165-C AVR1709
G601207AE020YS
JACK222 00D9630146005 TER,RCA 1PIN
G600107A0000YS
JACK223 90M-YT004640R MODULE JSR1165-C AVC1509
G601207AE020YS
JACK231,232 00D9630244703 JACK,D3.5 EARPHONE AVR1709, 689
G40130802000YS
L101C 00D9630049005 COIL INDUCTOR 0.5UH
D330R50000000S
L101FL 00D9630049005 COIL INDUCTOR 0.5UH
D330R50000000S
L101FR 00D9630049005 COIL INDUCTOR 0.5UH
D330R50000000S
L101SL 00D9630049005 COIL INDUCTOR 0.5UH
D330R50000000S
L101SR 00D9630049005 COIL INDUCTOR 0.5UH
D330R50000000S
L231 nsp BEAD,COIL 3580 AVR1709, 689
7610010030000S
RLY541 00D9630218506 RELAY BC3-24 24V 2A
G680240202040S
TP101-105 nsp CN.WAFER 3P
L101530140310S
Ref. No. Part No. Part Name Remarks Q'ty New
