Denon AVR-1609 Service Manual

90
AVR-1709/1609/1519/1509/689/589, AVC-1509
OTHERS PARTS GROUP
BD301-304 nsp COIL,BEAD MB-160808
D340160800060S
CN102 nsp CN,WIRE 4P AVR1709, 689 L000271040040S
CN301 nsp CN,WIRE 2P L000401020050S
CN302A nsp CN,WIRE 5P L000450050010S
CN303A nsp CN,WIRE 3P L000450030010S
CN304 nsp CN,WIRE 3P L000500030051S
CN305 nsp CN,WIRE 10P L000700100031S
CN541 nsp CN,WIRE 3P L000251030081S
CP101 nsp CN.WAFER 10P L102526701000S
CP103 nsp CN.WAFER 7P L101200100710S
CP105 nsp CN.WAFER 4P ANGLE L102526800400S
CP301B 00D9630368506 CN.FPC 35P L131103500010S
CP302 nsp CN.WAFER 3P ANGLE L102526803010S
CP304 nsp CN.WAFER 3P L101200100310S
CP305 nsp CN.WAFER 10P L101200101020S
CP306 nsp CN.WAFER 3P L101200100320S
CP306A nsp CN.WAFER 7P L101100030710S
CP306B nsp CN.WAFER 7P L101100040710S
CP307A nsp CN.WAFER 7P L101100030710S
CP307B nsp CN.WAFER 7P L101100040710S
CP806 nsp CN.WAFER 7P CN.WAFER 10P L101100041010S
CP1006 nsp CN.WAFER 7P CN.WAFER 10P L101100041010S
G301 nsp RING,TER WIRE 120MM/1P 8410121010060S
G302 nsp RING,TER WIRE 120MM/1P 8410121010130S
G304 nsp RING,TER WIRE 80MM/2P 8410800020040S
JACK501 963646001690S TER,BOARD SCREW 8P G614108V1010M
S
JACK502 00D9630257208 TER,BOARD SCREW 4P AVR1509, 589, AVC1509 G612405E0200YS
JACK502 963646001690S TER,BOARD SCREW 8P AVR1709, 689 G614108V1010MS
JACK502A 00D9630158608 TER,BOARD SCREW 2P AVR1509, 589, AVC1509 G611201A0200YS
JACK503 00D9630158608 TER,BOARD SCREW 2P AVR1709, 689 G611201A0200YS
JK302 00D9630294708 JACK,D6.5 PHONE G402PJ612AG0YS
L302 nsp COIL INDUCTOR 10UH D330100700520S
L303 nsp COIL INDUCTOR 100UH D330101001020S
RLY542-545 00D9630366201 RELAY G5PA-28-MC 24V 5A G680240502030S
RLY546 00D9630366201 RELAY G5PA-28-MC 24V 5A AVR1709, 689 G680240502030S
RMC301 00D9630217808 MODULE,REMOCON
NJL34H380A
E940343800010S
z SW301 00D9630145802 SW,PUSH SDDL-005-S(C-UL) G000122006060S
SW301A 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW301C 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW302A 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW302B 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW302C 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW303A 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW303B 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
SW303C 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
Ref. No. Part No. Part Name Remarks Q'ty New
