23
Calculation
Set up speakers (Audyssey
®
Setup)
10
Repeat step 9, measuring positions 3 to 6.
When measurement of position 6 is completed, a
“Measurements Complete.” message is displayed.
Audyssey Setup
Measurements Complete.
Calculation
MultEQ
Repeat Last Test
11
Select “Calculation” and then press ENTER.
Measuring results are analyzed, and the frequency response of
each speaker in the listening room is determined.
Audyssey Setup
Calibration complete! Now Calculating...
Please wait...
MultEQ
75%
•Analysis takes several minutes to complete. The more speakers
and measurement positions that there are, the more time it takes
to perform the analysis.
Measurement (2nd – 6th)
•In this step, you will perform measurements at multiple positions
(two to six positions) other than the main listening position.
•Just one position can be measured but measuring multiple positions
increases the accuracy of the correction of acoustic distortion within
the listening area.
9
Move the setup microphone to
position 2, select “Continue”,
and then press ENTER.
The measurement of the second
position starts. Measurements can be
made in up to six positions.
Audyssey Setup
Place the microphone at ear level at 3rd
Listening position.
Continue
Calculation
MultEQ XT
Repeat Last Test
Audyssey Setup
Place the microphone at ear level at 2nd
Listening position.
Continue
Calculation
MultEQ
•To skip measuring the third and subsequent listening position, use
ui to select “Calculation” and press ENTER to proceed to step
12.
•To measure the second position again, use ui to select “Repeat
Last Test” and press ENTER.
To Next Page
