PARTS LIST OF EXPLODED VIEW
s
zParts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
1611E3 : U.S.A. & Canada model 1611E2 : Europe model 1611E1C : China model
591E3 : U.S.A. & Canada model 591EA : Australia model 1621E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
22A nsp PCB FRONT ASSY 1611BKE3 7025HK0923013 1 *
22A nsp PCB FRONT ASSY 591BKE3 7025HK0923023 1 *
22A nsp PCB FRONT ASSY 1611BKE2 7025HK0923033 1 *
22A nsp PCB FRONT ASSY 591BKEA 7025HK0923043 1 *
22A nsp PCB FRONT ASSY 1611SPE1C 7025HK0923063 1 *
22A nsp PCB FRONT ASSY 1621SPE1C 7025HK0923073 1 *
22A nsp PCB FRONT ASSY 1611SPE2 7025HK0923083 1 *
11 - PCB FUNCTION
14 - PCB H/P
22 - PCB FRONT
23 - PDB FUNCTION_CNT
26 - PCB GUIDE_L
29 - PCB TOP_GUIDE
33 nsp PCB 7CH_AMP ASSY 1611BKE3 7025HK0923010 1 *
33 nsp PCB 5CH_AMP ASSY 591BKE3 7025HK0923020 1 *
33 nsp PCB 5CH_AMP ASSY 1611BKE2 7025HK0923030 1 *
33 nsp PCB 5CH_AMP ASSY 591BKEA 7025HK0923040 1 *
33 nsp PCB 5CH_AMP ASSY 1611SPE1C 7025HK0923060 1 *
33 nsp PCB 5CH_AMP ASSY 1621SPE1C 7025HK0923070 1 *
33 nsp PCB 5CH_AMP ASSY 1611SPE2 7025HK0923080 1 *
50 nsp PCB AUDIO_VIDEO ASSY 1611BKE3 7025HK0923014 1 *
50 nsp PCB AUDIO_VIDEO ASSY 591BKE3 7025HK0923024 1 *
50 nsp PCB AUDIO_VIDEO ASSY 1611BKE2 7025HK0923034 1 *
50 nsp PCB AUDIO_VIDEO ASSY 591BKEA 7025HK0923044 1 *
50 nsp PCB AUDIO_VIDEO ASSY 1611SPE1C 7025HK0923064 1 *
50 nsp PCB AUDIO_VIDEO ASSY 1621SPE1C 7025HK0923074 1 *
50 nsp PCB AUDIO_VIDEO ASSY 1611SPE2 7025HK0923084 1 *
53A nsp PCB REG_CNT ASSY 1611BKE3 7025HK0923012 1 *
53A nsp PCB REG_CNT ASSY 591BKE3 7025HK0923022 1 *
53A nsp PCB REG_CNT ASSY 1611BKE2 7025HK0923032 1 *
53A nsp PCB REG_CNT ASSY 591BKEA 7025HK0923042 1 *
53A nsp PCB REG_CNT ASSY 1611SPE1C 7025HK0923062 1 *
53A nsp PCB REG_CNT ASSY 1621SPE1C 7025HK0923072 1 *
53A nsp PCB REG_CNT ASSY 1611SPE2 7025HK0923082 1 *
51 - PCB SIDE_CNT
52 - PCB REG
53 - PCB REG_CNT
57 - PCB FRONT_CNT
54A nsp PCB SPK ASSY 1611BKE3 7025HK0923011 1 *
54A nsp PCB SPK ASSY 591BKE3 7025HK0923021 1 *
54A nsp PCB SPK ASSY 1611BKE2 7025HK0923031 1 *
54A nsp PCB SPK ASSY 591BKEA 7025HK0923041 1 *
Ref. No. Part No. Part Name Remarks Q'ty New
54A nsp PCB SPK ASSY 1611SPE1C 7025HK0923061 1 *
54A nsp PCB SPK ASSY 1621SPE1C 7025HK0923071 1 *
54A nsp PCB SPK ASSY 1611SPE2 7025HK0923081 1 *
54 - PCB SPK
55 - PCB SMPS
56 963189009980D PCB HDMI ASSY 1611BKE3 7025HK0923016 1 *
56 963189009990D PCB HDMI ASSY 591BKE3 7025HK0923026 1 *
56 nsp PCB HDMI ASSY 1611BKE2 7025HK0923036 1 *
56 nsp PCB HDMI ASSY 1611SPE1C 7025HK0923066 1 *
56 nsp PCB HDMI ASSY 1621SPE1C 7025HK0923076 1 *
56 nsp PCB HDMI ASSY 1611SPE2 7025HK0923086 1 *
56 nsp PCB HDMI ASSY 591BKEA 7025HK0923046 1 *
1 963416010070D WINDOW DISPLAY 1611BKE3 5077212762060S 1 *
1 963416010570D WINDOW DISPLAY
1611SPE2,1611BKE2,1611SPE1C,
1621SPE1C,591BKE3,591BKEA
5077212762070S 1 *
2 963412000570D KNOB FUNCTION(KD) BK
5080211761000SZ
1
2 412510003031D KNOB FUNCTION SP 5087211901000S 1
3 00D9630362109 BADGE DENON BK 5630210028300S 1
3 00D9630362202 BADGE DENON SP 5630210028400S 1
4 963402009930D PANEL FRONT 1611BKE3 3067214901000S 1 *
4 963402009940D PANEL FRONT 1611BKE2 3067214901100S 1 *
4 963402009950D PANEL FRONT 1611SPE2 3067214901200S 1 *
4 963402009960D PANEL FRONT 1611SPE1C 3067214901210S 1 *
4 963402009970D PANEL FRONT 1621SPE1C 3067214901220S 1 *
4 963402010010D PANEL FRONT 591BKE3,591BKEA 3067214921000S 1 *
5 00D9630137807 LENS STANDBY 3710210503000S 1
6 nsp CUSHION SIDE 4050213095000S 2 *
7 963411002820S BUTTON-ASSY STANDBY(KD) BK
5098212361000SZ
1
7 00D9630221904 BUTTON-ASSY STANDBY SP
5097212368030SZ
1
8 00D9630362305 BUTTON 2KEY 1611BKE3,1611BKE2 5097213351000S 1
8 00D9630362501 BUTTON 2KEY
1611SPE2,1611SPE1C,1621SPE1C
5097213351110S 1
8 963411001390D BUTTON 2KEY 591BKE3,591BKEA 5097213591000S 1
12 963419010060D COVER RCA BK 4317215141000S 1 *
12 963419011380D COVER RCA SP 4317215141100S 1 *
15 963412000560D KNOB VOLUME(KD) BK
5080211751000SZ
1
15 412510002038D KNOB VOLUME SP 5087211891000S 1
16 963411003370D BUTTON 1KEY 1611BKE3,1611BKE2 5097213791000S 1
16 963412003670D BUTTON 1KEY
1611SPE2,1611SPE1C,1621SPE1C
5097213791100S 1
16-1 963411003770D BUTTON BUTTON 1KEY 591BKE3,591BKEA 5097213801000S 1
17 963411003380D BUTTON CURSOR 5KEY BK 5097213811000S 1
17 963411003680D BUTTON CURSOR 5KEY SP 5097213811100S 1
18 00D9630364700 BUTTON 3KEY 1611BKE3,1611BKE2 5097213331000S 1
18 00D9630364906 BUTTON 3KEY
1611SPE2,1611SPE1C,1621SPE1C
5097213331110S 1
92
NOTE :
Please change the destination-resistors when changing 591BKE3 (963189009990D) to other
destination.
Please refer to
destination-resistors 85,86,87 page.
(SCHEMATIC DIAGRAMS : 19/23,20/23,21/23)
R2704(19/23) R2906(20/23) R3122(21/23) R3119(21/23)
591BKE3 10K OPEN 18K 3.3K
591BKEA 4.7K OPEN 3.3K 18K
1611BKE2 4.7K 33 10K OPEN
1611SPE1C 4.7K OPEN 10K 10K
1621SPE1C 4.7K OPEN 22K 10K
