Denon AVR-1705 Service Manual

14
AVR-1705/685
78 RDS_CLK I RDS(TDA7330) CLOCK
79 FLAG3 I Special flag for ROM update
80 FLAG2 I DSP operation check flag
81 FLAG1 I NON USE
82 FLAG0 I EPROM chip select control for DSP
83 VIDEO_SEL1
84 VDEO_SEL2
85 REMOCON REMOTE CONTROL SIGNAL INPUT
86 NC - -
87 GND GND
88 V
SS
VSS
89 V
DD
(BACK UP) VDD FOR BACK UP
90 NC - -
91 NC - -
92 PLL_DATA O PLL CONTROL (LC72131)
93 PLL_CLK O PLL CONTROL (LC72131)
94 PLL_DT_IN I PLL CONTROL (LC72131)
95 TU_MUTE O TUNER MUTE
96 ST I STEREO DETECT
97 TUNED I TUNE DETECT
98 PLL_CE O PLL CONTROL (LC72131)
99 2090_CLK(VIDEO) O BU2090 CLK
100 2090_DATA(VIDEO) O BU2090 DATA
Pin
No.
Pin Name I/O Function

Denon AVR-1705 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	6.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX
Digital Signal Processing (DSP)	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	230 W
Optical drive included	No
HDMI in	0
Composite video in	4
S-Video inputs quantity	3
Digital audio optical in	1
S-Video outputs quantity	2

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	10900 g
