Denon AVR-1705 Service Manual

55
AVR-1705/685
VIDEO P.W.B. UNIT ASS'Y (for AVR-1705/685 U.S.A. & Canada model only)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC600-604 00D 963 0147 907 TK15420MTL
IC605 00D 963 0148 207 LA7108M
IC606 00D 963 0148 003 TA1270BF
IC607 00D 963 0074 504 BU2090F
IC608 00D 963 0116 103 MM74HC4053MX
IC609 00D 963 0148 100 TC90A69F
IC610,611 00D 963 0147 907 TK15420MTL
IC612,613 00D 963 0148 304 BA7626F
IC614 00D 963 0116 200 NJM2274R
IC615 00D 963 0074 504 BU2090F
IC616 00D 963 0148 304 BA7626F
Q600,601 00D 960 0005 105 KTA1266Y
Q601C 00D 963 0121 208 KRC107M
Q601C1 00D 963 0121 208 KRC107M
Q602 00D 960 0005 105 KTA1266Y
Q602C 00D 963 0121 208 KRC107M
Q602C1 00D 963 0121 208 KRC107M
Q603 00D 960 0005 105 KTA1266Y
Q603C 00D 963 0121 208 KRC107M
Q603C1 00D 963 0121 208 KRC107M
Q604 00D 960 0005 105 KTA1266Y
Q604C 00D 963 0121 208 KRC107M
Q604C1 00D 963 0121 208 KRC107M
Q605 00D 960 0005 105 KTA1266Y
Q605C 00D 963 0121 606 KRC107S
Q606 00D 963 0102 803 2SA933S
Q606C 00D 963 0102 803 2SA933S
Q607 00D 963 0121 208 KRA107M
Q607C 00D 963 0120 801 KRC102S
Q608,609 00D 960 0005 105 KTA1266Y
Q610 00D 963 0102 803 2SA933S
Q612 00D 960 0005 105 KTA1266Y
Q616 00D 963 0121 208 KRA107M
D601C 00D 960 0197 000 KDS160
D602 00D 960 0197 000 KDS160
D602C 00D 960 0197 000 KDS160
D603 00D 960 0197 000 KDS160
D603C 00D 960 0197 000 KDS160
D604 00D 960 0197 000 KDS160
D604C 00D 960 0197 000 KDS160
D605 00D 960 0197 000 KDS160
D605C 00D 960 0197 000 KDS160
D606C 00D 960 0197 000 KDS160
D607C1 00D 960 0197 000 KDS160
D608 00D 960 0197 000 KDS160
D608C1 00D 960 0197 000 KDS160
D609 00D 960 0197 000 KDS160
D609C 00D 960 0197 000 KDS160
D610 00D 960 0095 500 MTZJ5.1B
D610C 00D 960 0197 000 KDS160
D611 00D 960 0197 000 KDS160
D611C 00D 960 0197 000 KDS160

Denon AVR-1705 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	6.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX
Digital Signal Processing (DSP)	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	230 W
Optical drive included	No
HDMI in	0
Composite video in	4
S-Video inputs quantity	3
Digital audio optical in	1
S-Video outputs quantity	2

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	10900 g
