Denon AVR-1705 Service Manual

51
AVR-1705/685
DSP P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC802,803 00D 963 0113 106 OPTICAL GP1FA513RZ
IC804 00D 963 0147 402 ADSP-21266
IC805 00D 963 0146 908 LH28F800BJE
IC807 00D 963 0096 100 LC89057W
IC808 00D 963 0096 207 AD1837
IC809-811 00D 960 0266 805 MM74LCX244
IC812 00D 960 0266 902 MM74HCT244
IC814,815 00D 963 0102 308 MM74HC00MTCX
IC815A 00D 963 0043 807 BA4510F
IC816 00D 963 0147 208 74LVX157
IC816A 00D 963 0043 807 BA4510F
IC817A 00D 963 0024 004 NJM2068M
IC818 00D 963 0147 305 74LCX573
IC818A 00D 963 0024 004 NJM2068M
IC819 00D 963 0147 305 74LCX573
IC819A 00D 963 0024 004 NJM2068M
IC820 00D 963 0147 101 SN74LVC139A
IC820A 00D 963 0024 004 NJM2068M
IC821 00D 963 0096 003 74LCX74MTC
IC822 00D 960 0159 501 KIA7805API
IC823 00D 963 0111 603 RC1117-3.3
IC824 00D 963 0147 509 RC1117-1.2
IC825 00D 963 0096 003 74LCX74MTC
IC827 00D 963 0146 801 IC63LV1024-10T
Q804C 00D 960 0196 603 KTC2874B
Q804FL 00D 960 0196 603 KTC2874B
Q804FR 00D 960 0196 603 KTC2874B
Q804SBR 00D 960 0196 603 KTC2874B
Q804SL 00D 960 0196 603 KTC2874B
Q804SR 00D 960 0196 603 KTC2874B
Q804SW 00D 960 0196 603 KTC2874B
Q808 00D 963 0120 801 KRC102S
Q809 00D 963 0120 704 KRA102S
D801 00D 960 0197 000 KDS160
D803 00D 960 0197 000 KDS160
RESISTORS GROUP
R831-833 00D 963 0120 908 COIL,BEAD 121J
CAPACITORS GROUP
C801 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C802,803 00D 963 9004 591 C,CERAMIC 22PF-J/50V
C805 00D 963 9004 591 C,CERAMIC 22PF-J/50V
C807 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C808 00D 963 9006 434 CAP.E. 47UF/16V
C812 00D 963 9005 927 C,ELECT 0.1UF-M/50V
C813 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C814 00D 963 9006 434 CAP.E. 47UF/16V

Denon AVR-1705 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	6.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX
Digital Signal Processing (DSP)	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	230 W
Optical drive included	No
HDMI in	0
Composite video in	4
S-Video inputs quantity	3
Digital audio optical in	1
S-Video outputs quantity	2

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	10900 g
