Denon AVR-1705 Service Manual

52
AVR-1705/685
C815 00D 963 9005 312 C,ELECT 100UF-M/10V
C816 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C817 00D 963 9005 778 C,ELECT 10UF-M/50V
C818 00D 963 9005 749 C,ELECT 1UF-M/50V
C819 00D 963 9005 901 C,ELECT 470UF-M/10V
C821 00D 963 9005 901 C,ELECT 470UF-M/10V
C830 00D 963 9005 901 C,ELECT 470UF-M/10V
C831,832 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C833 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C835 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C836,837 00D 963 9004 685 C,CERAMIC 1000PF-K/50V
C838-841 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C842 00D 963 9004 591 C,CERAMIC 22PF-J/50V
C843-846 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C847 00D 963 9004 591 C,CERAMIC 22PF-J/50V
C848-857 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C858 00D 960 9009 856 C,CERAMIC 0.022UF-Z/50V
C859,860 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C861,862 00D 963 9005 998 C,CERAMIC 24PF-J/50V
C863 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C864 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C864L 00D 963 9006 434 CAP.E. 47UF/16V
C864R 00D 963 9006 434 CAP.E. 47UF/16V
C865 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C865L 00D 963 0141 806 C,CERAMIC 120PF-J/50V
C865R 00D 963 0141 806 C,CERAMIC 120PF-J/50V
C866-868 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C869L 00D 963 9004 575 C,CERAMIC 100PF-J/50V
C869R 00D 963 9004 575 C,CERAMIC 100PF-J/50V
C870 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C871 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C871L 00D 960 9009 500 C,FILM 0.001UF-J/100V
C871R 00D 960 9009 500 C,FILM 0.001UF-J/100V
C872 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C873 00D 963 9006 340 CAP.E. 100UF/25V
C873C 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873FL 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873FR 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SBR 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SL 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SR 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SW 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C874 00D 963 9006 340 CAP.E. 100UF/25V
C874C 00D 963 9006 146 C,CERAMIC 560pF-J/50V
C874FL 00D 963 9006 146 C,CERAMIC 560pF-J/50V
C874FR 00D 963 9006 146 C,CERAMIC 560pF-J/50V
C874SBR 00D 963 9006 146 C,CERAMIC 560pF-J/50V
C874SL 00D 963 9006 146 C,CERAMIC 560pF-J/50V
C874SR 00D 963 9006 146 C,CERAMIC 560pF-J/50V
C874SW 00D 963 9006 146 C,CERAMIC 560pF-J/50V
C875 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V
C875C 00D 963 9005 778 C,ELECT 10UF-M/50V
C875FL 00D 963 9005 778 C,ELECT 10UF-M/50V
C875FR 00D 963 9005 778 C,ELECT 10UF-M/50V
C875SBR 00D 963 9005 778 C,ELECT 10UF-M/50V
C875SL 00D 963 9005 778 C,ELECT 10UF-M/50V
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1705 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	6.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX
Digital Signal Processing (DSP)	Yes
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	230 W
Optical drive included	No
HDMI in	0
Composite video in	4
S-Video inputs quantity	3
Digital audio optical in	1
S-Video outputs quantity	2

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	10900 g
