DISASSEMBLY
Disassemble in order of the arrow in the following gure.
In the case of the re-assembling, assemble it in order of the reverse of the following ow.
In the case of the re-assembling, observe "attention of assembling".
If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
PCB H/P
(Ref. No. of EXPLODED VIEW : P1)
PCB FUNCTION
(Ref. No. of EXPLODED VIEW : P2)
PCB FUNCTION_CNT
(Ref. No. of EXPLODED VIEW : P3)
PCB FRONT
(Ref. No. of EXPLODED VIEW : P4)
PCB V.AUX
(Ref. No. of EXPLODED VIEW : P5)
RADIATOR ASSY
Refer to "DISASSEMBLY
7. RADIATOR ASSY"
and "EXPLODED VIEW"
PCB 7CH-AMP ASSY
(Ref. No. of EXPLODED VIEW : P8)
PCB GUIDE_TOP
(Ref. No. of EXPLODED VIEW : P9)
PCB GUIDE_L
(Ref. No. of EXPLODED VIEW : P10)
POWER TRANS MAIN
Refer to "DISASSEMBLY
3. POWER TRANS MAIN"
and "EXPLODED VIEW"
POWER TRANS MAIN
(Ref. No. of EXPLODED VIEW : 31)
TOP COVER
PCB HDMI
Refer to "DISASSEMBLY
2. PCB HDMI"
and "EXPLODED VIEW"
PCB HDMI ASSY
(Ref. No. of EXPLODED VIEW : P16
PCB SMPS/PCB SPK
Refer to "DISASSEMBLY
5. PCB SMPS/PCB SPK"
and "EXPLODED VIEW"
PCB SMPS
(Ref. No. of EXPLODED VIEW : P18)
PCB SPK
(Ref. No. of EXPLODED VIEW : P19)
PCB REG/PCB REG_CNT
Refer to "DISASSEMBLY
6. PCB REG/PCB REG_CNT"
and "EXPLODED VIEW"
PCB REG
(Ref. No. of EXPLODED VIEW : P11)
PCB REG_CNT
(Ref. No. of EXPLODED VIEW : P12)
PCB AUDIO_VIDEO ASSY
s
Refer to "DISASSEMBLY
4. PCB AUDIO_VIDEO ASSY"
and "EXPLODED VIEW"
PCB AUDIO_VIDEO
ASSY
(Ref. No. of EXPLODED VIEW : P13)
PCB SIDE_CNT
(Ref. No. of EXPLODED VIEW : P14)
PCB FRONT_CNT
(Ref. No. of EXPLODED VIEW : P20)
