Denon AVR-1712 Service Manual

8
About the photos used for "descriptions of the DISASSEMBLY" section
• The shooting direction of each photograph used herein is indicated on the left side of the respective photograph as
"Shooting direction: ***".
• Refer to the diagram below about the shooting direction of each photograph.
• Photographs with no shooting direction indicated were taken from the top of the set.
The viewpoint of each photograph
(Shooting direction)
［View from the top］
Front side
Shooting direction: B
Shooting direction: DShooting direction: C
Shooting direction: A
