40
n Specify a name for the preset broadcast station
(Preset Name)
You can set the name to the preset broadcast station or change it.
Up to eight characters can be input.
1
Press FM to switch the input source to “FM”.
2
Press OPTION.
The option menu screen is displayed.
3
Use ui to select “Preset Name”, then press ENTER.
The Preset Name screen is displayed.
GTV ScreenH
TUNE+/- OPTION
AUTO
CH+/-
FM
CH 1
FM 87.50MHz
Tune Preset Option
Direct Tune
Option
Preset Memory
Tune Mode
Auto Preset
Preset Name
Preset Skip
GDisplay of this unitH
Preset Name
Listening to FM broadcasts
4
Use o p to select the group of the broadcast station
you want to name, then press ENTER.
The screen that lets you edit the preset name is displayed.
•Each time
o p is pressed, the setting is changed as shown below.
1 – 8 9 – 16 25 – 3217 – 24
41 – 4849 – 56 33 – 40
GTV ScreenH
CH 3 FM 98.10 MHz
CH 2 FM 89.10 MHz
CH 1 FM 87.50 MHz
Preset Group
CH 6 FM 90.10 MHz
CH 5 FM 90.10 MHz
CH 8 FM 90.10 MHz
CH 7 FM 90.10 MHz
CH 4 FM107.90 MHz
Preset Name
1-8
GDisplay of this unitH
Group : 1- 8
5
Use ui to select the broadcast station you want to
name, then press ENTER.
GTV ScreenH
Preset Name
CH 1 FM 87.50 MHz
Set Defaults
GDisplay of this unitH
1 FM 87.50MHz
6
Use uio p to select a name label, then press
ENTER.
The screen that lets you edit the preset name is displayed.
•If you select “Set Defaults”, then the unit returns to displaying the
frequency.
7
Enter the characters, then press
OK
.
•For character input, see page82.
8
Press BACK twice.
The display returns to the playback screen.
Basic version
Advanced version
Information
Basic version
DVD

Table of Contents

Other manuals for Denon AVR-1713

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-1713 and is the answer not in the manual?

Denon AVR-1713 Specifications

General IconGeneral
Receiver type-
Audio output channels5.1 channels
Audio A/D Converter (ADC)24-bit/96kHz
Power output per channel (1KHz@6 Ohm)120 W
Power output per channel (20-20KHz@8 Ohm)80 W
HDMI in5
Composite video in2
Digital audio optical in1
Ethernet LANYes
Preset stations quantity56
Internet radio services supportedLast.fm
Supported video modes1080p
Analog signal format systemNTSC, PAL
DisplayLCD
HDMI version1.4
Product colorBlack
Audio decodersDolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibilityNot supported
Graphical user interface (GUI) languageEnglish, French, German
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.5 W
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth332 mm
Width435 mm
Height151 mm
Weight8300 g
