Denon AVR-1713 Service Manual

112
Ref. No. Part No. Part Name Remarks Q'ty New
P3 943412100720D KNOB, VOLUME SP CBN1A263C73 1
P4 943446100590D PLATE, VOLUME KNOB CGX1A469 1
P5 42151002100AD DENON BADGE BK CGB1A247H67 1
P5 42151002101AD DENON BADGE
SP - 1
P6 943402102090D PANEL, FRONT 1613BKE3 CGW1A520RHZB63 1 *
P6 943402102100D PANEL, FRONT 1713BKE3 CGW1A520RHYB63 1 *
P6 943402102110D PANEL, FRONT 1713BKE2 CGW1A520RHXB63 1 *
P6 943402102120D PANEL, FRONT 1713BKE1C CGW1A520RHWB63 1 *
P6 943402102130D PANEL, FRONT 1713SPE1C CGW1A520RGZG45 1 *
P6 943402102140D PANEL, FRONT 1723SPE1C CGW1A520RGYG45 1 *
P7 943423100310D INDICATOR, POWER CGL1A299 1
P8 943411101750D BUTTON, POWER BK CBT1A1167 1
P8 943411101760D BUTTON, POWER SP CBT1A1167C73 1
P9 943411101770D BUTTON, 10KEY CBT1A1164 1
P10 943407100020D FOOT CKL1A190 4
P11 00D9430202902 CUSHION, FOOT CHG2A289 4
P12 nsp HOLDER, PCB CHE170 2
P13 943419100250D SHEET,TOP BK CGX1A492Z 2
P13 943419100250D SHEET,TOP SP CGX1A492Y 2
P14 45451000500AM STOPPER, SHEET BK CMH1A306Z 8
P14 45451000501AM STOPPER, SHEET SP CMH1A306Y 8
P15 nsp
BUSHING ,ACCORD
1613E3, 1713E3,
1713E1C, 1723E1C
CHR1A028 1
P16 nsp RUBBER CHG1A113 1
★
P17 nsp CLAMPER CHR301 5
★
P18 nsp LOCKER CRE1A037 10
★
P19 nsp LABEL,HOT CQB1A906Z 1
★
P20 nsp LABEL,POP
1613BKE3 CQB1A1096Z 1 *
★
P20 nsp LABEL,POP 1713BKE3 CQB1A1097Z 1 *
★
P20 nsp LABEL,POP 1713BKE2 CQB1A1098Z 1 *
★
P20 nsp LABEL,POP 1713BKE1C, 1713SPE1C CQB1A1100Z 1 *
★
P20 nsp LABEL,POP 1723SPE1C CQB1A1102Z 1 *
★
P21 nsp TAPE,HEMELON CHS1A032 3
M1 nsp EARTH,HDMI CMC1A422 1
M2 nsp EARTHPLATE, HDMI CMC1A431 1
M3 nsp EARTHPLATE, USB CMC1A430 1
M4 nsp EARTHPLATE, MIC CMC1A429 1 *
M5 nsp CHASSIS, BOTTOM CUA1A335 1
M6 943403100570D CABINET,TOP
BK CKC1A215K117 1
M6 943403100580D CABINET,TOP SP CKC1A215D11 1
M7 nsp BRACKET,PCB CMD1A398 1
M8 nsp HEATSINK CMY6A381 1
M9 nsp BRACKET, H/S PCB CMD1A802 2
M10 nsp BRACKET, PCB CMD1A803 2
M11 nsp
SMPS, BRACKET CMD1A790 1
M12 nsp PANEL, REAR
1613BKE3 CKF1A455Z 1 *
M12 nsp PANEL, REAR
1713BKE3 CKF2A455Z 1 *
M12 nsp PANEL, REAR
1713BKE2 CKF3A455Z 1 *
M12 nsp PANEL, REAR
1713BKE1C,
1713SPE1C
CKF1A455Y 1 *
M12 nsp PANEL, REAR 1723SPE1C CKF1A455X 1 *

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
