Denon AVR-1713 Service Manual

163
DIGITAL PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC711 236810057606S
I.C,HDMIMUX CVIADV3002BSTZ
IC721 943236012460S I.C,HDMITransceiver(LQFP-144P) CVIADV7623BSTZ
IC722 943248101050S I.C , OSD Serial Flash (AVR1613E3) 1613 E3 CVIANAM1674AV *
IC722 943248101060S
I.C , OSD Serial Flash (AVR1713E3) 1713 E3 CVIANAM1675AV *
IC722 943248101070S
I.C , OSD Serial Flash (AVR1713E2) 1713 E2 CVIANAM1676AV *
IC722 943248101090S
I.C , OSD Serial Flash (AVR1713E1C) 1713 E1C CVIANAM1677AV *
IC722 943248101100S
I.C , OSD Serial Flash (AVR1723E1C) 1723 E1C CVIANAM1678AV *
IC724 943239100760S
I.C,DE/MUX(8CHANALOG,TSSOP-16P) CVITC74VHC4051AFT *
IC751 nsp
I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC752 nsp I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC753 nsp I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC754 nsp I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC755 943239100730S I.C,SYSTEMRESET(4.8V,SOT-25A) CVIPST8448NR *
IC756 943239010400S
I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133
IC761 943243100860S I.C , MAIN MCU(AVR1613E3) 1613 E3 CVIANAM1662AV *
IC761 943243100870S
I.C , MAIN MCU(AVR1713E3) 1713 E3 CVIANAM1663AV *
IC761 943243100880S
I.C , MAIN MCU(AVR1713E2) 1713 E2 CVIANAM1664AV *
IC761 943243100900S
I.C , MAIN MCU(AVR1713E1C) 1713 E1C CVIANAM1665AV *
IC761 943243100910S
I.C , MAIN MCU(AVR1723E1C) 1723 E1C CVIANAM1666AV *
IC762 943239100720S
I.C,EEPROM(256KBIT,SOP-8P) CVIR1EX24256BSAS0A *
IC771 963239002150S
I.C,OCTALBUFFER/DRIVER CVISN74LVC244APWR
IC772 00D2623444902 I.C,QUAD2-INPUTANDGATE CVITC74VHC08FT
IC781 00D2623077900 IC,HEXINVERTER HVITC74VHCU04FT
IC782 236810062608S I.C,DIR CVILC89058W-E
IC783 943243100920S I.C , PLD(AVR1613/1713) CVIANAM1680AV *
IC791 943245100310S
I.C,DSPSHARC(LQFP-176P) CVIADSP21487KSWZ-2B *
IC792 943246012690S
I.C,64MSDRAM CVIW9864G6JH-6
IC793 943248101110S I.C , DSP(AVR1613/1713) CVIANAM1681AV *
IC811 236810086505S
I.C,ADC(96kHz24-Bit) CVIAK5358BET
IC812 236810073509S I.C,DAC(8CH192kHz24-Bit) CVIAK4358VQ
IC813 00D2631289900 EOLitemI.C,OPAMP(DUAL/LOWNOISE) CVIAZ4580MTR-E1
IC814 00D2631289900 EOLitemI.C,OPAMP(DUAL/LOWNOISE) CVIAZ4580MTR-E1
IC815 00D2631289900 EOLitemI.C,OPAMP(DUAL/LOWNOISE) CVIAZ4580MTR-E1
IC831 23681011260AS I.C,NetworkMediaprocessor(LFBGA-320P) CVIDM860A *
IC832 nsp
I.C,1GNANDFLASH(48P-TSOP1) CVIH27U1G8F2BTR-BC
IC833 246810063608S I.C,256MSDRAM CVIW9825G6JH-6
IC851 943239100700S I.C,EthernetTransceiver(QFN-24P) CVILAN8720ACPTR *
IC853 23671011050AS
I.C,IPODAUTHENTICATIONFROMD&M CVI23671011050AS_DM
IC854 943239100710S I.C,CURRENTLIMITE(1.5A,UDFN-6P) CVINCP380HMU15AATBG *
IC855 943239100690S
I.C,2CHDAC(32BIT,384KHZ,TSSOP-20P) 1713E3 CVIPCM5100PWR *
IC856 943239010400S
I.C,REGULATOR(3.3V/TO-252) 1713E3 CVINJM2845DL133
IC861 nsp I.C,HDMItransmitterwithI/PConverter(FBGA-289 CVISLI11131 *
IC871 nsp
I.C,HDMIBUFFER CVIAD8195ACPZ
IC891 943235100520S I.C,INPUTWITH8CHVOLUME(52PLQFP) CVINJU72340AFH3 *
IC901 90M-HC109700R
I.C,VIDEOS/W(JRC) CVINJM2595MTE1
Q7101 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q7102 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q7103 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q7104 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q7105 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q7106 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q7107 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q7108 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q7201 943215500020S T.R,RT1P141C(10K-10K) 1713E3 CVTRT1P141C
Q7202 943216500040S T.R,RT1N241C(22K-22K) 1713E3 CVTRT1N241C
Q7204 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7205 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7206 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7501 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7502 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q7503 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
NOTE
:
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
