Denon AVR-1713 Service Manual

164
Ref. No. Part No. Part Name Remarks Q'ty New
Q7504 943229500020S
MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q7505 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7506 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q7507 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7508 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q7509 00D2710326904 T.R,2SA1954 CVT2SA1954
Q7510 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q7511 00D2710326904 T.R,2SA1954 CVT2SA1954
Q7512 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q7513 943214500020S T.R,2SC3052 CVT2SC3052
Q7514 00D2710326904 T.R,2SA1954 CVT2SA1954
Q7515 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q7516 00D2710326904 T.R,2SA1954 CVT2SA1954
Q7517 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q7606 943214500020S T.R,2SC3052 CVT2SC3052
Q7607 943214500020S T.R,2SC3052 CVT2SC3052
Q7608 943214500030S T.R,MUTE CVTINC2001AC1
Q7701 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q7702 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q7703 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q7705 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q7706 943214500020S T.R,2SC3052 CVT2SC3052
Q7709 943214500020S T.R,2SC3052 CVT2SC3052
Q7712 943214500020S T.R,2SC3052 CVT2SC3052
Q8301 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q8302 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q8701 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q8702 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q8901 943215500030S T.R,RT1P441C(47K-47K) 1713E3 CVTRT1P441C
Q8902 943216500050S T.R,RT1N441C(47K-47K) 1713E3 CVTRT1N441C
Q8903 943215500030S T.R,RT1P441C(47K-47K) 1713E3 CVTRT1P441C
Q8905 943214500030S T.R,MUTE 1713E3 CVTINC2001AC1
Q8907 943214500030S T.R,MUTE 1713E3 CVTINC2001AC1
Q8908 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C
Q8909 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q8910 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C
Q8913 943214500030S T.R,MUTE CVTINC2001AC1
D7101 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30
D7104 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
D7114 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
D7124 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
D7134 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
D7204 nsp RES,CHIP(1005/5%/10Kohm) 1713E3 CRJ06IJ103T
D7231 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30
D7232 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D7501 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP
D7502 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D7503 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D7601 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D7602 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP
D8505 943209001080S DIODE,CHIP,SWITCHING 1713E3 CVD1SS355T
D8506 943209001080S DIODE,CHIP,SWITCHING 1713E3 CVD1SS355T
D8905 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D8906 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D8907 90M-HD302380R DIODE,ZENER,1/2W,3.6V CVDZJ3.6BT
D8908 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D8909 00D9430196306 DIODE,ZENER,1/2W,7.5V CVDZJ7.5BT
D8910 00D9430196306 DIODE,ZENER,1/2W,7.5V CVDZJ7.5BT
RESISTORS GROUP
R7101 nsp
RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7102 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R7103 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7106 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7107 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
