Denon AVR-1713 Service Manual

165
Ref. No. Part No. Part Name Remarks Q'ty New
R7108 nsp
RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7109 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R7110 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7113 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7114 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7115 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7116 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R7117 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7120 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7121 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7122 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7123 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R7124 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7127 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7128 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7129 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7130 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7131 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7133 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7134 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7135 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7136 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7137 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7140 nsp RES,CHIP(1005/5%/2.2Kohm) CRJ06IJ222T
R7141 nsp RES,CHIP(1005/5%/2.2Kohm) CRJ06IJ222T
R7142 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7201 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7203 nsp RES,CHIP(1005/5%/75ohm) CRJ06IJ750T
R7204 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7205 nsp RES,CHIP(1005/5%/1Kohm) 1713E3 CRJ06IJ102T
R7206 nsp RES,CHIP(1005/5%/22Kohm) 1713E3 CRJ06IJ223T
R7207 nsp RES,CHIP(1005/5%/47Kohm) 1713E3 CRJ06IJ473T
R7210 nsp RES,CHIP(1005/5%/47Kohm) 1713E3 CRJ06IJ473T
R7211 nsp RES,CHIP(1005/5%/4.7Kohm) 1713E3 CRJ06IJ472T
R7212 nsp RES,CHIP(1608/1%/1.6Kohm) CRJ10DF1601T
R7213 nsp RES,CHIP(1608/1%/2Kohm) CRJ10DF2001T
R7214 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7216 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7218 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7219 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7220 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7221 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7222 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7223 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7224 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7226 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7227 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7228 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7229 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7230 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R7231 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R7232 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7233 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7234 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7235 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7236 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7237 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7238 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7239 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7241 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R7243 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7244 nsp RES,CHIP(1608/5%/390Kohm) CRJ10DJ394T
R7245 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7246 nsp RES,CHIP(1005/1%/1Kohm) CRJ06IF1001T
R7247 nsp RES,CHIP(1005/1%/1Kohm) CRJ06IF1001T
R7250 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7252 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
