Denon AVR-1713 Service Manual

166
Ref. No. Part No. Part Name Remarks Q'ty New
R7254 nsp
RES,CHIP(1608/5%/51ohm) CRJ10DJ510T
R7255 nsp RES,CHIP(1608/5%/51ohm) CRJ10DJ510T
R7261 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7262 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7263 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7264 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7265 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7266 nsp RES,CHIP(1608/5%/5.1ohm) CRJ10DJ5R1T
R7267 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T
R7268 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T
R7269 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7270 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7271 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7272 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7273 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7274 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7276 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7278 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7280 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7281 nsp RES,CHIP(1005/5%/5.6Kohm) CRJ06IJ562T
R7282 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7283 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7284 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7286 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7288 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7289 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7290 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7291 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7292 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7293 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7294 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7295 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7296 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7297 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7298 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7299 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7300 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7301 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7501 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7502 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7505 nsp RES,CHIP(1608/1%/47Kohm) CRJ10DF4702T
R7506 nsp RES,CHIP(1608/5%/680Kohm) CRJ10DJ684T
R7507 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R7508 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7512 90M-NN000680R RES,CHIP(1608/1%/300Kohm) CRJ10DF3003T
R7513 nsp RES,CHIP(1608/5%/1.5Mohm) CRJ10DJ155T
R7514 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R7515 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7516 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7519 nsp RES,CHIP(1608/1%/470Kohm) CRJ10DF4703T
R7520 00MNN05105610 RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T
R7521 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R7526 nsp RES,CHIP(1608/1%/120Kohm) CRJ10DF1203T
R7527 00MNN05105610 RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T
R7528 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R7529 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7530 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7531 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7532 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7533 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7534 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7535 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7536 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7537 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7538 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T
R7539 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7540 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
