Denon AVR-1713 Service Manual

167
Ref. No. Part No. Part Name Remarks Q'ty New
R7541 nsp
RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7542 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7543 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7544 nsp RES,CHIP(1005/5%/100Kohm) CRJ06IJ104T
R7545 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7546 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7547 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T
R7548 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7549 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T
R7550 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7601 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7602 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7603 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7604 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7605 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7609 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7611 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7616 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7617 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7618 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7619 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7620 00MNN05330610 RES,CHIP(1608/5%/33ohm) CRJ10DJ330T
R7621 00MNN05330610 RES,CHIP(1608/5%/33ohm) CRJ10DJ330T
R7622 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7625 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7626 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7627 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7628 00MNN05330610 RES,CHIP(1608/5%/33ohm) CRJ10DJ330T
R7629 00MNN05330610 RES,CHIP(1608/5%/33ohm) CRJ10DJ330T
R7631 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7632 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7633 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7634 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7638 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7639 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7641 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7643 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7644 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7645 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7650 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7651 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7652 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7653 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7654 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7655 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7656 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7657 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7660 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7661 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7663 nsp RES,CHIP(1608/5%/0ohm) 1713E3 CRJ10DJ0R0T
R7663 nsp RES,CHIP(1608/5%/10Kohm) 1713E1C CRJ10DJ103T
R7663 nsp RES,CHIP(1608/5%/18Kohm) 1613E3 CRJ10DJ183T
R7663 nsp RES,CHIP(1608/5%/3.3Kohm) 1723E1C CRJ10DJ332T
R7664 nsp RES,CHIP(1608/5%/0ohm) 1713E3 CRJ10DJ0R0T
R7664 nsp RES,CHIP(1608/5%/10Kohm) 1713E1C CRJ10DJ103T
R7664 nsp RES,CHIP(1608/5%/18Kohm) 1723E1C CRJ10DJ183T
R7664 nsp RES,CHIP(1608/5%/3.3Kohm) 1613E3 CRJ10DJ332T
R7665 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7666 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7667 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7668 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7669 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7677 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7678 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7679 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7681 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7682 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
