Denon AVR-1713 Service Manual

168
Ref. No. Part No. Part Name Remarks Q'ty New
R7683 nsp
RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7684 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7685 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7686 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7687 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7688 nsp RES,CHIP(1005/5%/100Kohm) CRJ06IJ104T
R7689 nsp RES,CHIP(1005/5%/2.2Mohm) CRJ06IJ225T
R7690 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7691 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7692 nsp RES,CHIP(1005/5%/100Kohm) CRJ06IJ104T
R7693 nsp RES,CHIP(1005/5%/220Kohm) CRJ06IJ224T
R7694 nsp RES,CHIP(1005/5%/27Kohm) CRJ06IJ273T
R7695 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T
R7696 nsp RES,CHIP(1005/5%/1.2Kohm) CRJ06IJ122T
R7698 nsp RES,CHIP(1005/5%/33ohm) 1713E3 CRJ06IJ330T
R7701 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7702 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7703 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7704 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R7705 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R7706 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R7707 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R7708 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R7709 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7710 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7711 00MNN05474610 RES,CHIP(1608/5%/470Kohm) CRJ10DJ474T
R7713 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7715 nsp RES,CHIP(1005/5%/3.9Kohm) CRJ06IJ392T
R7717 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7718 nsp RES,CHIP(1005/5%/27Kohm) CRJ06IJ273T
R7719 nsp RES,CHIP(1005/5%/2.7Kohm) CRJ06IJ272T
R7720 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7721 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7722 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7723 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7724 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7725 nsp RES,CHIP(1005/5%/27Kohm) CRJ06IJ273T
R7726 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7727 nsp RES,CHIP(1005/5%/2.7Kohm) CRJ06IJ272T
R7728 nsp RES,CHIP(1005/5%/3.9Kohm) CRJ06IJ392T
R7729 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7730 00MNN05124610 RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T
R7731 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R7735 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7736 00MNN05124610 RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T
R7737 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R7741 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7801 nsp RES,CHIP(1005/5%/150ohm) CRJ06IJ151T
R7802 nsp RES,CHIP(1005/5%/150ohm) CRJ06IJ151T
R7803 nsp RES,CHIP(1005/5%/470ohm) CRJ06IJ471T
R7806 00MNN05334610 RES,CHIP(1608/5%/330Kohm) CRJ10DJ334T
R7807 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R7808 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7813 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7816 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7817 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7818 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7819 nsp RES,CHIP(1005/5%/220ohm) CRJ06IJ221T
R7820 00MNN05330610 RES,CHIP(1608/5%/33ohm) CRJ10DJ330T
R7821 nsp RES,CHIP(1005/5%/1Mohm) CRJ06IJ105T
R7822 nsp RES,CHIP(1005/5%/820ohm) CRJ06IJ821T
R7823 nsp RES,CHIP(1005/5%/3.3Kohm) CRJ06IJ332T
R7824 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7825 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7826 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7828 00MNN05330610 RES,CHIP(1608/5%/33ohm) CRJ10DJ330T
R7829 00MNN05330610 RES,CHIP(1608/5%/33ohm) CRJ10DJ330T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
