Denon AVR-1713 Service Manual

169
Ref. No. Part No. Part Name Remarks Q'ty New
R7830 nsp
RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7833 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7834 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7835 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R7836 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7837 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7840 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7841 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7842 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7843 00MNN05330610 RES,CHIP(1608/5%/33ohm) CRJ10DJ330T
R7901 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7902 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7903 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7904 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7905 nsp RES,CHIP(1005/5%/1Mohm) CRJ06IJ105T
R7906 nsp RES,CHIP(1005/5%/47ohm) CRJ06IJ470T
R7907 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7909 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7910 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7911 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7913 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7914 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7915 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R7916 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7917 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7918 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7919 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7920 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7922 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7923 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7924 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7925 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7926 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7927 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7928 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7929 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7930 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7933 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7935 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7936 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7938 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7939 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7940 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R7941 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7942 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7943 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7944 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7945 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7946 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7947 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7948 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7949 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R7952 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R7953 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7954 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R7955 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7956 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R7957 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8102 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8104 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R8105 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8107 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R8108 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8109 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R8110 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R8113 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8114 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
