Denon AVR-1713 Service Manual

170
Ref. No. Part No. Part Name Remarks Q'ty New
R8115 nsp
RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T
R8116 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R8117 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8118 nsp RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T
R8119 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R8120 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8121 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8122 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8123 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8124 nsp RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T
R8125 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R8126 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8127 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8128 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R8129 nsp RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T
R8130 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8131 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8132 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8133 nsp RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T
R8134 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R8135 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8137 nsp RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T
R8138 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R8139 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8140 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8141 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8142 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8144 00MNN05123610 RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T
R8145 00MNN05181610 RES,CHIP(1608/5%/180ohm) CRJ10DJ181T
R8146 00MNN05181610 RES,CHIP(1608/5%/180ohm) CRJ10DJ181T
R8147 00MNN05123610 RES,CHIP(1608/5%/12Kohm) CRJ10DJ123T
R8149 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8150 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8151 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8152 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R8153 00MNN05682610 RES,CHIP(1608/5%/6.8Kohm) CRJ10DJ682T
R8154 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8155 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R8156 00MNN05682610 RES,CHIP(1608/5%/6.8Kohm) CRJ10DJ682T
R8157 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8158 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8159 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8160 nsp RES,CHIP(1608/0.5%/3.9Kohm) CRJ06DD392TP
R8161 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R8162 00MNN05682610 RES,CHIP(1608/5%/6.8Kohm) CRJ10DJ682T
R8163 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8164 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8165 00MNN05682610 RES,CHIP(1608/5%/6.8Kohm) CRJ10DJ682T
R8166 00MNN05154610 RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T
R8167 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8169 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8170 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8225 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8230 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8301 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8302 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8303 nsp RES,CHIP(1005/5%/1.5Kohm) CRJ06IJ152T
R8304 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R8305 nsp RES,CHIP(1005/5%/12Kohm) CRJ06IJ123T
R8306 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8307 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8308 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8310 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R8311 nsp RES,CHIP(1005/5%/1Mohm) CRJ06IJ105T
R8312 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8313 nsp RES,CHIP(1005/5%/1.8Kohm) CRJ06IJ182T
R8314 nsp RES,CHIP(1005/5%/1.2Kohm) CRJ06IJ122T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
