Denon AVR-1713 Service Manual

171
Ref. No. Part No. Part Name Remarks Q'ty New
R8317 nsp
RES,CHIP(1005/5%/47ohm) CRJ06IJ470T
R8318 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8319 nsp RES,CHIP(1005/5%/2.7Kohm) CRJ06IJ272T
R8320 nsp RES,CHIP(1005/5%/1.5Kohm) CRJ06IJ152T
R8322 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8324 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8327 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8328 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8329 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8330 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8331 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8332 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8333 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8334 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8336 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R8338 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8343 nsp RES,CHIP(1005/5%/1.5Kohm) CRJ06IJ152T
R8344 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8349 nsp RES,CHIP(1005/5%/1Mohm) CRJ06IJ105T
R8501 nsp RES,CHIP(1005/5%/3.3ohm) CRJ06IJ3R3T
R8502 nsp RES,CHIP(1005/5%/3.3ohm) CRJ06IJ3R3T
R8504 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R8505 nsp RES,CHIP(1005/5%/10ohm) CRJ06IJ100T
R8506 nsp RES,CHIP(1608/5%/51ohm) CRJ10DJ510T
R8507 nsp RES,CHIP(1608/5%/51ohm) CRJ10DJ510T
R8510 nsp RES,CHIP(1005/5%/33ohm) CRJ06IJ330T
R8512 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8513 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8514 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8516 943124003370S RES,CHIP(1608/1%/12Kohm) CRJ10DF1202T
R8520 90M-NN000600R RES,CHIP(1608/1%/1.5Kohm) CRJ10DF1501T
R8521 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8522 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8523 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8524 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8525 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8536 nsp RES,CHIP(1005/5%/10Kohm) 1713E3 CRJ06IJ103T
R8542 nsp RES,CHIP(1608/5%/51ohm) CRJ10DJ510T
R8543 nsp RES,CHIP(1608/5%/51ohm) CRJ10DJ510T
R8544 nsp RES,CHIP(1608/1%/100ohm) CRJ10DF1000T
R8561 nsp RES,CHIP(1005/5%/470ohm) 1713E3 CRJ06IJ471T
R8562 nsp RES,CHIP(1005/5%/470ohm) 1713E3 CRJ06IJ471T
R8563 nsp RES,CHIP(1005/5%/10Kohm) 1713E3 CRJ06IJ103T
R8564 nsp RES,CHIP(1608/5%/10Kohm) 1713E3 CRJ10DJ103T
R8567 nsp RES,CHIP(1005/5%/10Kohm) 1713E3 CRJ06IJ103T
R8569 nsp RES,CHIP(1608/5%/0ohm) 1713E3 CRJ10DJ0R0T
R8570 nsp RES,CHIP(1608/5%/0ohm) 1713E3 CRJ10DJ0R0T
R8603 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8604 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8608 943124001530S RES,CHIP(1608/1%/470ohm) CRJ10DF4700T
R8609 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8610 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8611 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8612 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8613 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8614 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8615 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8616 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8617 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8618 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8619 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8620 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8621 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8622 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8623 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8624 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8625 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
