Denon AVR-1713 Service Manual

172
Ref. No. Part No. Part Name Remarks Q'ty New
R8626 nsp
RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8627 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8628 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8629 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8630 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8631 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8632 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8633 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8634 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8635 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8636 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8637 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8638 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8639 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8640 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8641 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8642 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8643 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8644 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8645 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8646 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8648 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8649 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8650 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8651 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8652 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8653 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8654 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8655 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8656 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8657 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8659 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8660 nsp RES,CHIP(1005/5%/100ohm) CRJ06IJ101T
R8661 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8662 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8663 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8664 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8665 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8666 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8667 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8668 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8669 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8670 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8671 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8672 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8673 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8674 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8675 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8676 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8677 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8678 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8679 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8680 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8681 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8682 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8683 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8684 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8685 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8686 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8687 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8688 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8689 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8690 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8691 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8692 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8693 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8694 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
