Denon AVR-1713 Service Manual

173
Ref. No. Part No. Part Name Remarks Q'ty New
R8695 nsp
RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8696 nsp RES,CHIP(1005/5%/10Kohm) CRJ06IJ103T
R8697 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8701 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R8702 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R8703 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R8704 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R8706 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R8710 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T
R8711 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T
R8712 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R8714 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8715 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8717 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8718 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8720 nsp RES,CHIP(1005/5%/4.7Kohm) CRJ06IJ472T
R8722 nsp RES,CHIP(1005/5%/2Kohm) CRJ06IJ202T
R8723 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R8901 00MNN05271610 RES,CHIP(1608/5%/270ohm) CRJ10DJ271T
R8902 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8903 00MNN05273610 RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T
R8904 00MNN05561610 RES,CHIP(1608/5%/560ohm) CRJ10DJ561T
R8905 00MNN05271610 RES,CHIP(1608/5%/270ohm) CRJ10DJ271T
R8906 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8907 00MNN05273610 RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T
R8908 00MNN05561610 RES,CHIP(1608/5%/560ohm) CRJ10DJ561T
R8909 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8910 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8911 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8912 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8913 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8917 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8918 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8919 00MNN05105610 RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T
R8920 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8921 00MNN05105610 RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T
R8922 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8923 00MNN05105610 RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T
R8924 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8925 00MNN05105610 RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T
R8926 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8937 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8938 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8939 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8940 943125500060S RES,M-OXIDEFILM(1W/150ohm) CRG1SANJ151RT
R8941 943125500060S RES,M-OXIDEFILM(1W/150ohm) CRG1SANJ151RT
R8942 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8943 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8944 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8945 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R8946 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8947 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8948 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8949 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8950 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8951 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8952 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R8953 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R8954 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R8955 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R8956 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R8957 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8958 00MNN05101610 RES,CHIP(1608/5%/100ohm) 1713E3 CRJ10DJ101T
R8959 00MNN05101610 RES,CHIP(1608/5%/100ohm) 1713E3 CRJ10DJ101T
R8960 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R8961 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8962 nsp RES,CHIP(1608/5%/10Kohm) 1713E3 CRJ10DJ103T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
