Denon AVR-1713 Service Manual

174
Ref. No. Part No. Part Name Remarks Q'ty New
R8963 nsp
RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8964 00MNN05102610 RES,CHIP(1608/5%/1Kohm) 1713E3 CRJ10DJ102T
R8965 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R8966 00MNN05474610 RES,CHIP(1608/5%/470Kohm) 1713E3 CRJ10DJ474T
R8967 00MNN05474610 RES,CHIP(1608/5%/470Kohm) CRJ10DJ474T
R8968 00MNN05471610 RES,CHIP(1608/5%/470ohm) 1713E3 CRJ10DJ471T
R8969 nsp RES,CHIP(1608/5%/10Kohm) 1713E3 CRJ10DJ103T
R8971 00MNN05471610 RES,CHIP(1608/5%/470ohm) 1713E3 CRJ10DJ471T
R8972 00MNN05104610 RES,CHIP(1608/5%/100Kohm) 1713E3 CRJ10DJ104T
R8973 00MNN05104610 RES,CHIP(1608/5%/100Kohm) 1713E3 CRJ10DJ104T
R8974 00MNN05221610 RES,CHIP(1608/5%/220ohm) 1713E3 CRJ10DJ221T
R8976 nsp RES,CHIP(1608/5%/10Kohm) 1713E3 CRJ10DJ103T
R8977 00MNN05471610 RES,CHIP(1608/5%/470ohm) 1713E3 CRJ10DJ471T
R8978 00MNN05471610 RES,CHIP(1608/5%/470ohm) 1713E3 CRJ10DJ471T
R8979 00MNN05104610 RES,CHIP(1608/5%/100Kohm) 1713E3 CRJ10DJ104T
R8980 00MNN05104610 RES,CHIP(1608/5%/100Kohm) 1713E3 CRJ10DJ104T
R8981 00MNN05221610 RES,CHIP(1608/5%/220ohm) 1713E3 CRJ10DJ221T
R8982 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R8983 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R8985 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R8986 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R8987 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R8988 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R8989 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8990 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8991 00MNN05821610 RES,CHIP(1608/5%/820ohm) CRJ10DJ821T
R8992 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8994 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R8996 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R8999 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R9000 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R9001 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T
R9002 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T
R9003 00MNN05182610 RES,CHIP(1608/5%/1.8Kohm) CRJ10DJ182T
R9004 nsp RES,CHIP(1608/1%/82ohm) CRJ10DF82R0T
R9005 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R9006 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
RN721 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN722 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN781 nsp RES,CHIP(1005/5%/33ohm*2) CRJ062IJ330T
RN782 nsp RES,CHIP(1005/5%/33ohm*2) CRJ062IJ330T
RN783 nsp RES,CHIP(1005/5%/33ohm*2) CRJ062IJ330T
RN784 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN785 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN786 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN791 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN792 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN793 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN794 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN795 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN796 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN797 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN798 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN799 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN800 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN802 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN803 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN804 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN805 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN806 nsp RES,CHIP(1005/5%/100ohm*4) CRJ064IJ101T
RN807 nsp RES,CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T
RN831 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN832 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN833 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN834 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN835 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
