Denon AVR-1713 Service Manual

175
Ref. No. Part No. Part Name Remarks Q'ty New
RN836 nsp
RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN837 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN838 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN839 nsp RES,CHIP(1005/5%/10Kohm*4) CRJ064IJ103T
RN840 nsp RES,CHIP(1005/5%/47ohm*4) CRJ064IJ470T
RN841 nsp RES,CHIP(1005/5%/47ohm*4) CRJ064IJ470T
RN843 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN844 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN845 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN846 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN847 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN848 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN849 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN850 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN851 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN852 nsp RES,CHIP(1005/5%/33ohm*4) 1713E3 CRJ064IJ330T
RN861 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN862 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
RN863 nsp RES,CHIP(1005/5%/33ohm*4) CRJ064IJ330T
CAPACITORS GROUP
C7105 nsp
CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7106 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7108 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7109 nsp CAP,CHIP(1608,50V/1000pF) CCUS1H102KC
C7111 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7112 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7113 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7114 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7204 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7205 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7206 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7207 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7208 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7209 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7210 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7211 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7212 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7213 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7214 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7215 nsp CAP,CHIP(1608,10V/1uF) CCUS1A105KC
C7218 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7219 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7220 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7221 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7222 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7223 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7224 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7225 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7228 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7229 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7230 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7231 nsp CAP,CHIP(1005,50V/1000pF) CCUI1H102KC
C7232 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7233 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7234 nsp CAP,CHIP(1608,50V/15pF) CCUS1H150JA
C7235 nsp CAP,CHIP(1608,50V/15pF) CCUS1H150JA
C7236 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7237 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7238 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7240 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7241 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7242 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7243 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7244 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7245 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
