Denon AVR-1713 Service Manual

176
Ref. No. Part No. Part Name Remarks Q'ty New
C7246 nsp
CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7247 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7248 943134500060S CAP,ELECT(50V/100uF) CCEA1HH101T
C7249 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7250 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7251 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7252 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7255 nsp CAP,CHIP(1608,10V/1uF) CCUS1A105KC
C7256 nsp CAP,CHIP(1608,10V/1uF) CCUS1A105KC
C7259 nsp CAP,CHIP(1608,10V/1uF) CCUS1A105KC
C7260 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7269 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7296 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7298 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7299 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7300 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7301 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7302 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7501 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7504 nsp CAP,CHIP(1005,25V/0.01uF) CCUI1E103KC
C7505 nsp CAP,CHIP(1005,50V/10pF) CCUI1H100JA
C7506 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C7507 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7508 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7509 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7512 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7515 nsp CAP,CHIP(1005,25V/0.01uF) CCUI1E103KC
C7516 nsp CAP,CHIP(1005,50V/15pF) CCUI1H150JA
C7517 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C7518 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7519 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7520 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7523 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7526 nsp CAP,CHIP(1005,25V/0.01uF) CCUI1E103KC
C7527 nsp CAP,CHIP(1005,50V/15pF) CCUI1H150JA
C7528 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C7529 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7530 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7531 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7534 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7537 nsp CAP,CHIP(1005,25V/0.01uF) CCUI1E103KC
C7538 nsp CAP,CHIP(1005,50V/15pF) CCUI1H150JA
C7539 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC
C7540 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7541 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7542 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7547 nsp CAP,CHIP(1005,25V/0.022uF) CCUI1E223KC
C7548 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7549 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7550 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7551 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7552 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7553 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7554 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7555 00D9430103905 CAP,ELECT(16V/470uF) CCEA1CH471T
C7557 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7559 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7560 00D9430103905 CAP,ELECT(16V/470uF) CCEA1CH471T
C7563 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7564 nsp CAP,CHIP(1005,25V/0.015uF) CCUI1E153KC
C7565 nsp CAP,CHIP(1608,10V/1uF) CCUS1A105KC
C7566 nsp CAP,CHIP(1005,16V/0.1uF) CCUI1C104KC
C7569 nsp CAP,CHIP(1608,10V/1uF) CCUS1A105KC
C7570 nsp CAP,CHIP(2012,6.3V/10uF,X5R) CCUC0J106KC
C7572 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C7573 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC
C7574 nsp CAP,CHIP(1608,50V/0.1uF) CCUS1H104KC

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
