Denon AVR-1713 Service Manual

162
Ref. No. Part No. Part Name Remarks Q'ty New
C5706 943134010460S
CAP,ELECT(30X35)WITHOUTPLATEONTHETOP CCET63VKL5682NKZ
C5707 943134010470S CAP,ELECT(50V/0.1uF) CCEA1HH0R1T
C5708 943134010480S CAP,ELECT(100V/100uF) CCEA2AH101E
C5710 nsp CAP,SEMICONDUCTOR CCFT1H104ZF
C5711 943134010660S CAP,ELECT(6.3V/470uF) CCEA0JH471T
C5712 nsp CAP,SEMICONDUCTOR CCFT1H104ZF
C5713 943134010660S CAP,ELECT(6.3V/470uF) CCEA0JH471T
C5716 963134010980S CAP,ELECT(16V/47uF) CCEA1CH470T
C5717 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
C5718 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5719 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5720 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5721 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5722 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5723 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
OTHERS PARTS GROUP
BK501 nsp
BRACKET,PCB CMD1A569
BN501 nsp WIRE ASS'Y CWB1B013150HC *
BN502 nsp
WIRE ASS'Y CWB1B007150HC *
BN505 nsp
WIRE ASS'Y CWB4B003250HC *
BN508 nsp
PINHEADER(11P,1.25mm,STRAIGHT,B-TO-B) CJP11GI281Z
CN503 nsp WAFER(3.96MM) CJP03GA148ZW
CN510 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN520 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN530 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN540 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN550 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
ET501 nsp PALTE,EARTH HJT1A025
JK501 943646010250S JACK,SPK(4PRR/BB,SCREW) CJJ5P011U
JK502 943646010240S JACK,SPK(6PRRR/BBB,SCREW CJJ5R008U
L5101 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5201 943115100310S
COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5301 943115100310S
COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5401 943115100310S
COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5501 943115100310S
COIL,SPEAKER(0.5UH) CLEY0R5KAD *
RY560 943682000810S
RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU
RY562 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU *
RY563 943682100270S
RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU *
RY564 943682100270S
RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU *
TU500 943183100200S
TUNER,FM(SCREW:FTYPE),SI4704-B20 1713E3
CNVMW004FV1-
S63SV
*
TU500 943183100210S
TUNER,RDS,FM(PALTYPE),SI4705-B20 1713E2
CNVMW104FV1-
S63V
*
TU500 943183100220S
TUNER,NORDS,FM(PALTYPE),SI4704-B20
171KE1C,
1723E1C
CNVMW004FV1-S63 *

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
