Denon AVR-1713 Service Manual

115
Ref. No. Part No. Part Name Remarks Q'ty New
4 943533101130D PAD,SNOW(R) CPS1A917 1
5 - INSTRUCTIONMANUALASS'Y - 1
5-1 nsp BATTERY,AAA2PCSINPACK CABR03PPB 2
5-2 35201006600AD CDMANUALASS'Y 1613E3 CFT1A052ZA 1 *
5-2 35201006500AD CDMANUALASS'Y 1713E3 CFT1A053ZA 1 *
5-2 35201006700AD CDMANUALASS'Y 1713E2 CFT1A054ZA 1 *
5-2 35201006800AD CDMANUALASS'Y 1713E1C, 1723E1C CFT1A055ZA 1 *
5-2 35201006900AD CDMANUALASS'Y 1723E1C CFT1A057ZA 1
*
5-3 nsp BAG,POLY(MANUAL) CPB1A197Z 1
★
5-4 nsp LABEL,BARCODE(MANUAL) CQB1A971 1
5-5 nsp LIST,S.S CQE1A226P 1
5-6 nsp CARD,WARRANTY
1613BKE3,
1713BKE3
CQE1A224Q 1
5-7 nsp CARD FOR CHINA INDENTIFICATION 1713E1C, 1723E1C CQE1A450Z 1
5-8 54111092900AD SAFETY INSTRUCTIONS(E3) 1613E3, 1713E3 CQE1A548Z 1 *
5-8 54111093000AD SAFETY INSTRUCTIONS (E2) 1713E2 CQE1A549Z 1
5-8 54111093100AD SAFETY INSTRUCTIONS (E1C) 1713E1C, 1723E1C CQE1A550Z 1
5-9 54111076000AD MANUAL,GUIDE 1613E3 CQX1A1648Z 1 *
5-9 54111075900AD MANUAL,GUIDE 1713E3 CQX1A1649Z 1 *
5-9 54111076100AD MANUAL,GUIDE 1713E2 CQX1A1650Z 1 *
5-9 54111076200AD MANUAL,GUIDE 1713E1C CQX1A1651Z 1 *
5-9 54111076300AD
MANUAL,GUIDE 1723E1C CQX1A1653Z 1 *
5-10 90M-ZA000230R FM1POLEANT(UL)
1613E3, 1713E3,
1713E1C, 1723E1C
CSA1A019Z 1
5-10 00D9430113403 FM1POLEANT 1713E2 CSA1A018Z 1
6 30701010300AD REMOCONASS'Y(RC-1168) 1713E3 RC-1168CF1 1 *
6 30701010200AD REMOCONASS'Y(RC-1169)
1613E3, 1713E2,
1713E1C, 1723E1C
RC-1169CF1 1 *
7 943531102270D BOX,OUTCARTON 1613E3 CPG1A963Y 1 *
7 943531102280D BOX,OUTCARTON 1713E3 CPG1A963X 1 *
7 943531102290D BOX,OUTCARTON 1713E2 CPG1A962U 1 *
7 943531102300D BOX,OUTCARTON 1713E1C CPG1A962T 1 *
7 943531102310D BOX,OUTCARTON 1723E1C CPG1A962R 1 *
8 nsp CONTROL,LABEL CQB1A993Z 1
9 nsp LABEL ,COLORLABEL(WHITE)
1713SPE1C,
1723SPE1C
CQB1A676 2
10 32401000800AD MIC AUDYSSEY ACM1HB CJXACM1HB 1
11 nsp WARRANTYCARD CHINA 1713E1C, 1723E1C CQE1A473Y 1
★
12 nsp LABEL,BARCODE(SET) CQB1A978 1

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
