Denon AVR-1713 Service Manual

73
Checking the USB device
YES
Is the USB device compatible with the set?
Are you using a USB hub?
Only mass storage devices in FAT16 or
FAT32 formats or MTPcompatible devices
and iPod (Remove some models) are
supported.
Don't use the USB hub.
NO
YES
NO
Checking the set (AV RECEIVER)
YES
YES
Is a voltage (5V) being supplied between pins 1 and 4 of JK101 on
the USB board (USB connector)?
The circuitry from IC853 on the DIGITAL board to JK101 on the USB
board is defective.
Is the wire properly connected between CN851 on the DIGITAL board
and BN104 on the USB board.
The IC854 and surrounding circuitry on the
DIGITAL board is defective.
Connect the wire properly.
NO
NO
5.2. USBdeviceisnotrecognized

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
