Denon AVR-1713 Service Manual

81
2CH IN 0dB
(200mV)
-10dB
-20dB
-40dB
-30dB
+10dB
+20dB
DSP
DAC
SPK OUT
NJU72340A
SURROUND
SURROUND CHANNEL
PLD
EPM3032A AK4358
ADSP21487
-50dB
0dB (200mVrms)
-10dB
-20dB
-40dB
-30dB
+10dB
+20dB
-50dB
+30dB
DAC
AK4358VQ
-10dBFS
0dBFS
-20dBFS=177Vrms
-30dBFS=56mVrms
-40dBFS
DD INPUT:-20dBFS SURR 1kHz
(MODE:MULTI CH STEREO)
ANA INPUT:200mVrms L+R 1kHz
L.P.F GAIN=+5dB
+4.07dB
-2.5dB
+1.0dB
+29dB
- DOLBY DIGITAL IN
GAIN setting of MASTER VOL 00dB
- ANALOG IN
-2.5dB
-2.5dB
=-2.5dB
=+1.0dB
(1) (2)
DSP OUTOPUT:-23dBFS
DSP OUTOPUT:-26.5dBFS
0dBFS=5Vpp=1.77Vrms
DIFF.OUT
FULL SCALE
LEVEL=2.0Vrms
AZ4580
MAX.OUTPUT 7.78Vrms
NJU72340 MAX.OUTPUT 3.8Vrms
+4.07dB
POWERAMP GAIN
4.27Vrms/8ohm
SPK OUT
PRE OUT
150mVrms
(1):Basic OFFSET of VOL=0dB ( PREAMPGAIN:+15.5dB at VOLMAX)
(2):OFFSET of the AD input ATT
+3.5dB
GAIN
ADJ.

Denon AVR-1713 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Digital audio optical in	1
Ethernet LAN	Yes
Preset stations quantity	56
Internet radio services supported	Last.fm
Supported video modes	1080p
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	151 mm
Weight	8300 g
