Denon AVR-1723 User Manual

76
D5.2V
D5.2V
DGND
DGND
MAINPOWER
TO DIGITAL SUPPLY_POWER
SMPS B'D
BK603
CMD1A629
OPTION
OPTION
E3,JP:100UF/200V
E2,E1C :100UF/400V
OPTION
OPTION
E3,JP:LF-4ZB-E273H
E2,E1C:LF-4ZB-E503H
OPTION
OPEN
R6004 330K
C6005 0.047uF(1608)
C6006 0.01uF(1608) C6007 OPEN
C6009 OPEN
R6006
1M(1608)
D6006 1N4007
D6005 1N4007
D6001 1N4007
D6002 1N4007
D6003 1N4007
D6004 1N4007
CX602
OPEN
R6013
15K(1608)
R6014
1K(1608)
R6012
270K(1608)
R6010
1M(0.2W)
R6008
2.2M(0.2W)
ZD608
39V
ZD609
39V
ZD610
39V
R6009
2.2M(0.2W)
ZD617
22V
ZD616
22V
ZD615
22V
ZD614
22V
ZD613
22V
ZD612
22V
ZD611
22V
C6011
1000P/1KV
R6015
6.8(0.2W)
C6013
47/25V
(NXA)
R601
1
10(1608)
D6012
1N4007ST
ZD620
39V
C6012
0.1uF(1608)
D6007
1N4007
ZD618
22V
C6008 50V/10UF(NXA)
D6008
1N4007
C6014 0.1uF(1608) C6015 4.7uF(1608) C6016 5600uF/6.3V(NXA)
C6017 5600uF/6.3V(NXA)
C6018 5600uF/6.3V(NXA)
C6019
OPEN
C6023
2200P 250V
C6024 0.1uF(1608)
R6017
3.3K(0.2W)
R6016
56(0.2W)
1
2
3
ANODE
REF
CATHODE
IC603 KIA2431AP
R6018
5.6K(0.2W)
C6020
0.1uF(1608)
R6019
22K-F(1608)
R6020
OPEN(1608)
R6021
OPEN(0.2W)
D6010 OPEN
R6022
6.8K-F
C6010
OPEN
ZD619
5.6V
1 2 3 4 5
BN601
WIRE/5P/2.5mm
Q6003
KTC3199Y
R6025
4.7K(1608)
R6024
10K(1608)
2
3
1
D6011
SRL3060P(60V)
C6002 0.01uF 250V
C6003
0.01uF 250V
R6026
OPEN(1608)
C6025 OPEN(1608)
1
2
3
4
5
6
7
8
10
11
T6001
1235
6 7 8 109
IC601
TOP258MG
R6023
OPEN
C6004
400V/100uF
R6027
2.2M
R6028
2.2M
R6029
2.2M
R6030
2.2M
R6031
1M(2125)
R6032
1M(2125)
R6033
1M(2125)
43
2 1
IC602
LF602
LF-4ZB-E273H
ZD621
7.5V
J6002
JUMPER
J6003
JUMPER
D
G
S
Q6002
INK0010AC1
After primary side rectification
(Caution: High voltage, electric shock)
Primary drain
(Caution: High voltage, electric shock)
After secondary rectifications
Operation waveform for each part
A B C
A B C
SMPS unit
(Unloaded)
Set
