Denon AVR-1802 Service Manual

13
AVR-1802/882
2SC1740S
2SC3199Y
KSA916Y
KSA992F
KSC1845F
KTA1266Y
KTA1268BL
KTC2874B
KTC3198Y
KTC3200BL
2SC2412K
KTC3880S
DTA114EK
DTA114YK
DTA144EK
DTC114EK
DTC114YK
DTC144EK
TOP
VIEW
E
B
C
TOP
VIEW
E
B
C
FRONT
VIEW
B
C
E
TOP VIEW
KDS160MTZJ3.3B
MTZJ5.1B
MTZJ5.6B
MTZJ6.8B
MTZJ7.5A
MTZJ7.5B
MTZJ11B
MTZJ18B
MTZJ20B
1N4007
1SS133
B
C
E
R1
R2
B
C
E
R1
R2
2SK117
FRONT
VIEW
S
G
D
DTA114ES
DTC114TS
DTC114YS
DTC144ES
FRONT
VIEW
B
C
E
DTA Series
DTC Series
DTA114EK
DTA114YK
R1
10kohm
/
W
R2
10kohm
/
W
DTA144EK
47kohm
/
W 47kohm
/
W
10kohm
/
W
47kohm
/
W
DTA114ES
10kohm
/
W 10kohm
/
W
DTC114EK
DTC114YK
10kohm
/
W 10kohm
/
W
DTC144EK
R1
R2
47kohm
/
W 47kohm
/
W
10kohm
/
W 47kohm
/
W
DTC144ES
47kohm
/
W 47kohm
/
W
DTC114YS
10kohm
/
W 47kohm
/
W
DTC114TS
10kohm
/
W¾
TOP VIEW
HL-50RDRF4T

TRANSISTORS

DIODES (LED included)
TOP VIEW
KBPC604

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
