Denon AVR-1802 Service Manual

43
AVR-1802/882
Ref. No. Part No. Part Name Remarks Q'ty
55 963 0082 101 Back panel for E3 1
963 0082 156 for 882EU 1
963 0082 114 for E2 1
963 0082 130 for E1, E1H, E1T 1
963 0082 143 for E1C 1
57 960 0192 403 Cord bush 1
58 960 0166 400 AC cord assy for E3, EU 1
960 0165 304 for E2 1
963 0060 408 for E1, E1T 1
960 0143 009 for E1H 1
963 0060 301 for E1C 1
59 960 0183 807 Terminal 1
60 963 0088 309 Cover for E3, EU, E2/Black 1
963 0088 312 for E2/Gold 1
61 963 0051 200 Cushion 2
64 963 0044 602 supporter for E2, E1, E1C, E1H, E1T 1
960 0093 104 Push livet for E2, E1, E1C, E1H, E1T 14
963 0061 407 FFC cable 1
A 963 0018 007 Screw (2S 3 × 8 ZNY/BH) 50
B 960 0108 701 Screw (2S 3 × 10 DOT BK) 43
C 963 0048 200 Screw (2S 3 × 10 ZNY/BH) 10
D 960 9008 417 Screw (3S 4 × 8 ZNY/BH) 4
E 963 0048 307 Screw (2S 4 × 8 DOT BK) 6
F 963 9004 009 Screw (2S 3 × 14 WASHER ZNY/HH) 15
G 960 9008 420 Screw (2S 3 × 8 WASHER) 3
H 963 0018 104 Screw (2S 3 × 17 ZNY/BH) 2
I 963 9004 025 Screw (3S 4 × 6 ZNY/BH) 6
J 963 9004 054 Screw (2S 3 × 15 ZNY/BH) 2

Denon AVR-1802 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	115 W
Power output per channel (20-20KHz@8 Ohm)	80 W
AC input voltage	120 V
AC input frequency	60 Hz
Equalizer	Yes
Audio decoders	DTS, Dolby Digital, Dolby Pro Logic II
3D	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	0
Composite video in	5
S-Video inputs quantity	4
Digital audio coaxial in	1
Digital audio optical in	3

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	171 mm
Weight	10900 g
