Denon AVR-1804 Service Manual

36
36
AVR-1804/884 / AVC-1880
D135 963 0096 508 Diode 1N4148
D136 963 0058 504 Zener diode MTZJ11B
D137 963 0096 508 Diode 1N4148
D138 963 0058 407 Diode IN4007
D141 963 0058 407 Diode IN4007
D142 963 0058 407 Diode IN4007
D143 963 0058 407 Diode IN4007
D144 963 0058 407 Diode IN4007
D145 963 0058 407 Diode IN4007
D146 963 0058 407 Diode IN4007
D148 963 0096 508 Diode 1N4148
D149 963 0058 407 Diode IN4007
D150 963 0058 407 Diode IN4007
D151 963 0096 508 Diode 1N4148
D152 963 0058 407 Diode IN4007
D153 963 0058 407 Diode IN4007
D154 960 0095 908 Zener diode MTZJ8.2B
D157 960 0014 905 Zener diode MTZJ20B
D158 963 0096 508 Diode 1N4148
D159 963 0096 508 Diode 1N4148
D160 963 0096 508 Diode 1N4148
ZD310 960 0095 607 Zener diode MTZJ5.6B
ZD311 960 0095 607 Zener diode MTZJ5.6B
RESISTORS GROUP
R104C Metal oxide 5.6 kohm 1W
R104FL Metal oxide 5.6 kohm 1W
R104FR Metal oxide 5.6 kohm 1W
R104SL Metal oxide 5.6 kohm 1W
R104SR Metal oxide 5.6 kohm 1W
R105C Metal oxide 5.6 kohm 1W
R105FL Metal oxide 5.6 kohm 1W
R105FR Metal oxide 5.6 kohm 1W
R105SL Metal oxide 5.6 kohm 1W
R105SR Metal oxide 5.6 kohm 1W
R106C 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R106FL 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R106FR 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R106SL 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R106SR 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107C 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107FL 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107FR 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107SL 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107SR 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R108C Metal oxide 0.22 ohm 1W
R108FL Metal oxide 0.22 ohm 1W
R108FR Metal oxide 0.22 ohm 1W
R108SL Metal oxide 0.22 ohm 1W
R108SR Metal oxide 0.22 ohm 1W
R109C Metal oxide 0.22 ohm 1W
R109FL Metal oxide 0.22 ohm 1W
R109FR Metal oxide 0.22 ohm 1W
R109SL Metal oxide 0.22 ohm 1W
R109SR Metal oxide 0.22 ohm 1W
R110C Metal oxide 0.22 ohm 1W
R110FL Metal oxide 0.22 ohm 1W
Ref. No. Part No. Part Name Remarks New

Denon AVR-1804 Specifications

General

Tuner	AM/FM
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Connector Type	RCA
Dimensions	434 x 168 x 391 mm
