Denon AVR-1804 Service Manual

37
37
AVR-1804/884 / AVC-1880
R110FR Metal oxide 0.22 ohm 1W
R110SL Metal oxide 0.22 ohm 1W
R110SR Metal oxide 0.22 ohm 1W
R111C Metal oxide 0.22 ohm 1W
R111FL Metal oxide 0.22 ohm 1W
R111FR Metal oxide 0.22 ohm 1W
R111SL Metal oxide 0.22 ohm 1W
R111SR Metal oxide 0.22 ohm 1W
R118C Metal oxide 10 ohm 1W
R118FL Metal oxide 10 ohm 1W
R118FR Metal oxide 10 ohm 1W
R118SL Metal oxide 10 ohm 1W
R118SR Metal oxide 10 ohm 1W
R119C Metal oxide 10 ohm 1W
R119FL Metal oxide 10 ohm 1W
R119FR Metal oxide 10 ohm 1W
R119SL Metal oxide 10 ohm 1W
R119SR Metal oxide 10 ohm 1W
R135 963 0045 203 Winding 0.1 ohm 5W
R136 963 0045 203 Winding 0.1 ohm 5W
R141 244 2043 982 Metal oxide 0.22 ohm 1W
R142 244 2043 982 Metal oxide 0.22 ohm 1W
R148 244 2043 982 Metal oxide 0.22 ohm 1W
R149 244 2043 982 Metal oxide 0.22 ohm 1W
R151 963 9003 343 Metal film 68ohm 1/4W
R154 963 0043 108 Metal film 2.2 Mohm 1/2W E3,EU,EUT
R179 963 9003 055 Metal film 47 kohm 1/4W (NB)
R181 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R184 Metal oxide 10 ohm 1W
R185 963 9005 655 Metal film 22 ohm 1/4W
R903H 960 9009 270 Metal film 470ohm 2W
R904H 960 9009 270 Metal film 470ohm 2W
VR101 960 0091 601 Semi fixed resistor 1 kohm
VR102 960 0091 601 Semi fixed resistor 1 kohm
VR103 960 0091 601 Semi fixed resistor 1 kohm
VR104 960 0091 601 Semi fixed resistor 1 kohm
VR105 960 0091 601 Semi fixed resistor 1 kohm
CAPACITORS GROUP
C101C 963 9005 888 Electrolytic 47uF/50V
C101FL 963 9005 888 Electrolytic 47uF/50V
C101FR 963 9005 888 Electrolytic 47uF/50V
C101SL 963 9005 888 Electrolytic 47uF/50V
C101SR 963 9005 888 Electrolytic 47uF/50V
C102C 963 9005 778 Electrolytic 10uF/50V
C102FL 963 9005 778 Electrolytic 10uF/50V
C102FR 963 9005 778 Electrolytic 10uF/50V
C102SL 963 9005 778 Electrolytic 10uF/50V
C102SR 963 9005 778 Electrolytic 10uF/50V
C103C 963 9003 084 Ceramic 100pF/500V
C103FL 963 9003 084 Ceramic 100pF/500V
C103FR 963 9003 084 Ceramic 100pF/500V
C103SL 963 9003 084 Ceramic 100pF/500V
C103SR 963 9003 084 Ceramic 100pF/500V
C104C 963 9003 084 Ceramic 100pF/500V
C104FL 963 9003 084 Ceramic 100pF/500V
C104FR 963 9003 084 Ceramic 100pF/500V
Ref. No. Part No. Part Name Remarks New

Denon AVR-1804 Specifications

General

Tuner	AM/FM
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Connector Type	RCA
Dimensions	434 x 168 x 391 mm
