2
AVR-1802/882
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to
chassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side
of the power cord is less than 460 kohms, the unit is defective.
SPECIFICATIONS
Audio section
Power amplifier
Rated output: Front: 80W + 80W (8Ω/ohms, 20Hz ~20kHz with 0.08% T.H.D)
115W + 115W (6Ω/ohms, 1kHz with 0.7% T.H.D) (U.S.A., Canada & Europe Models)
130W + 130W (6Ω/ohms, EIAJ) (Asia Model)
Center: 80W (8Ω/ohms, 20Hz ~20kHz with 0.08% T.H.D)
115W (6Ω/ohms, 1kHz with 0.7% T.H.D) (U.S.A., Canada & Europe Models)
130W (6Ω/ohms, EIAJ) (Asia Model)
Surround: 80W + 80W (8Ω/ohms, 20Hz ~20kHz with 0.08% T.H.D)
115W + 115W (6Ω/ohms, 1kHz with 0.7% T.H.D) (U.S.A., Canada & Europe Models)
130W + 130W (6Ω/ohms, EIAJ) (Asia Model)
Output terminals: Front: A or B 6 to 16Ω/ohms
A + B 12 to 16Ω/ohms
Center/Surround: 6 to 16Ω/ohms
Analog
LINE input - PRE OUT
Input Sensitivity/input impedance: 200mV/47kΩ/kohms
Frequency response: 10Hz~100kHz: + 1, −3dB (TONE DEFEAT ON)
S/N ratio: 100dB (IHF-A weighted) (TONE DEFEAT ON)
Video section
Standard video jacks
Input/output level and impedance: 1Vp-p, 75Ω/ohms
Frequency response: 5Hz~10MHz +1, −3dB
S-video jacks
Input/output level and impedance: Y (brightness) signal 1Vp-p, 75Ω/ohms
C (color) signal 0.286Vp-p, 75Ω/ohms
Frequency response: 5Hz~10MHz +1, −3dB
Tuner section
Receiving range: [FM] (note: µV at 75Ω/ohms, 0dBf =1x10
-15
W) [AM]
U.S.A. & Canada Models 87.50MHz~107.90MHz 520kHz~1710kHz
Europe &
Asia (for China) Models 87.50MHz~108.00MHz 522kHz~1611kHz
Asia (for Multiple voltage) Models 87.50MHz~107.90MHz (0.2MHz steps) 520kHz~1710kHz (10kHz steps)
87.50MHz~108.00MHz (0.05MHz steps) 522kHz~1611kHz (9kHz steps)
Usable sensitivity: 1.0 µV (11.2dBf) 18 µV
50dB quieting sensitivity: MONO 1.6 µV (15.3dBf)
STEREO 23 µV (38.5dBf)
S/N ratio: MONO 80dB (IHF-A weighted)
STEREO 75dB (IHF-A weighted)
Total harmonic distortion: MONO 0.15% (1kHz)
STEREO 0.3% (1kHz)
General
Power supply:
U.S.A., Canada Models AC120V, 60Hz
Europe Model AC230V, 50Hz
Asia (for Multiple voltage) Model AC115/230V, 50/60Hz
Asia (for China) Model AC220V, 50Hz
Power consumption: 4.5A (U.S.A. & Canada model), 230W (Europe & Asia model)
Maximum external dimensions: 434 (W) × 171 (H) × 417 (D)mm (17-3/32” × 6-47/64” × 16-7/16”)
Mass: 10.9kg (24lbs 0.5 oz)
Remote control unit (RC-897)
Batteries: R6P/AA Type(two batteries)
External dimensions: 54 (W) × 172.5 (H) × 29 (D)mm (2-1/8” × 6-51/64” × 1-9/64”)
Mass: 120g (Approx. 4.2 oz) (including batteries)
* For purposes of improvement, specifications and design are subject to change without notice.
