Dolby Digital mode (only with digital input) and DTS Surround (only with digital input)
1
Select the input source.
q Select an input source set to digital (COAXIAL/OPTICAL)
(see page 26).
INPUT MODE
(Main unit) (Remote control unit)
w Set the input mode to “AUTO” or DTS.
2
Select the STANDARD (Dolby/DTS Surround) mode.
(Remote control unit)
4
Play a program source with the , mark.
• The Dolby Digital indicator lights when
playing Dolby Digital sources.
DIGITAL
Light
23 2 2, 75, 6
1 1 4 3
5, 6
3
7
6
7
1
1
8
2
6
Playback with a digital input
• The DTS indicator lights when playing
DTS sources.
Light
Example: DVD
FUNCTION
(Main unit)
(Remote control unit)
STANDARD
(Main unit)
When performing this operation from the main unit’s panel,
press the SURROUND MODE button, then turn the SELECT
knob and select Dolby Pro Logic IIx or DTS NEO:6.
SELECT
SURROUND 
MODE
(Main unit)
Operate the SURROUND BACK button to switch Surround
Back CH ON/OFF.
(Remote control unit)
SURROUND
BACK
(Main unit)
• Lights when the SURROUND BACK button is on.
(Main unit)
SURROUND
BACK
Light
3
51
ENGLISH

Denon AVR-1905 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	80 W
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Digital Signal Processing (DSP)	Yes
HDMI in	0
Composite video in	4
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	3
S-Video outputs quantity	2
Ethernet LAN	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz

Weight and Dimensions

Depth	171 mm
Width	434 mm
Height	416 mm
Weight	11900 g
