Panel trasero
Consulte la página que se indica entre paréntesis ( ).
wq e r t y u i
Q0
Q2 Q1Q3 o
q Conector ZONE2 ······································································ (39)
w Terminales de antena HD Radio ············································ (19)
e Conectores de audio analógico ·······································(16 – 19)
r Conector PRE OUT ························································ (5, 33, 34)
t Conector S-VIDEO ··································································· (18)
y Conectores VIDEO ····························································· (16, 17)
u Conectores COMPONENT VIDEO ·········································· (17)
i Terminales de altavoces ··············································· (5, 33, 34)
o Toma de AC ··············································································· (5)
Q0 Conectores HDMI ···································································· (15)
Q1 Conectores de audio digital ············································· (16, 17)
Q2 Conector REMOTE CONTROL ················································ (20)
Q3 Conector DOCK CONTROL ····················································· (18)
NOTA
No toque los pines internos de los conectores en el panel trasero.
La descarga electrostática puede ocasionar daños permanentes a la
unidad.
