Denon AVR-2105 Service Manual

103
AVR-2105/885 / AVC-1890
LED302 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED305 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED306 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED307 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED308 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED309 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED310 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
CAPACITORS GROUP
BC201 00D 963 0061 504 Electrolytic 8200uF/5.5V
C201D 00D 960 9010 816 Ceramic 0.1uF/50V
C201E 00D 963 9004 517 Ceramic 0.022uF/50V
C201F 00D 963 9004 546 Ceramic 0.01uF/16V
C202 00D 963 9004 698 Ceramic chip 0.01uF/50V
C202D 00D 963 9004 546 Ceramic 0.01uF/16V
C202E 00D 963 9004 517 Ceramic 0.022uF/50V
C202F 00D 963 9004 546 Ceramic 0.01uF/16V
C203 00D 963 9004 698 Ceramic chip 0.01uF/50V
C204 00D 963 9006 476 Electrolytic 4.7uF/50V
C205 00D 963 9004 562 Ceramic 0.047uF/50V
C206 00D 963 9006 421 Electrolytic 47uF/10V
C207 00D 963 9004 546 Ceramic 0.01uF/16V
C208 00D 963 9004 805 Ceramic 270pF/50V
C209 00D 963 9006 308 Electrolytic 10uF/50V
C210 00D 963 9004 698 Ceramic chip 0.01uF/50V
C211 00D 963 9004 614 Ceramic chip 27pF/50V
C212 00D 963 9004 614 Ceramic chip 27pF/50V
C221 00D 963 9005 312 Electrolytic 100uF/10V
C228 00D 963 9004 575 Ceramic chip 100pF/50V
C230 00D 963 9004 575 Ceramic chip 100pF/50V
C231 00D 963 9004 575 Ceramic chip 100pF/50V
C232 00D 963 9004 575 Ceramic chip 100pF/50V
C233 00D 963 9004 575 Ceramic chip 100pF/50V
C234 00D 963 9004 575 Ceramic chip 100pF/50V
C238 00D 963 9006 366 Electrolytic 0.1uF/50V
C239 00D 963 9006 366 Electrolytic 0.1uF/50V
C242 00D 963 9004 685 Ceramic chip 1000pF/50V
C245 00D 963 9004 575 Ceramic chip 100pF/50V
C248 00D 963 9004 685 Ceramic chip 1000pF/50V
C249 00D 963 9004 737 Ceramic chip 0.022uF/25V
C251 00D 963 0020 202 Ceramic 0.1uF/50V
C252 00D 960 9010 816 Ceramic 0.1uF/50V
C257 00D 963 9006 308 Electrolytic 10uF/50V
C262 00D 963 9006 379 Electrolytic 1uF/50V
C263 00D 963 9006 379 Electrolytic 1uF/50V
C301 00D 963 9004 546 Ceramic 0.01uF/16V
C3010 00D 963 9006 421 Electrolytic 47uF/10V
C302 00D 963 9004 546 Ceramic 0.01uF/16V
C3020 00D 963 0020 202 Ceramic 0.1uF/50V
C303 00D 963 9004 546 Ceramic 0.01uF/16V
C303O 00D 963 9004 591 Ceramic chip 22pF/50V
C304 00D 963 9004 546 Ceramic 0.01uF/16V
C305 00D 963 9004 685 Ceramic chip 1000pF/50V
C306 00D 963 9004 575 Ceramic chip 100pF/50V
C307 00D 963 9004 575 Ceramic chip 100pF/50V
C308 00D 960 9010 816 Ceramic 0.1uF/50V
C309 00D 963 9004 737 Ceramic chip 0.022uF/25V
C310 00D 963 9004 753 Ceramic chip 0.047uF/50V
C311 00D 963 9005 406 Ceramic chip 30pF/50V
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
