Denon AVR-2105 Service Manual

246
AVR-2105/885 / AVC-1890
WIRING DIAGRAM
8P 15P13P
14P
3P
AC CORD
7P 9P
8P
5P
3P
6P 5P 5P 16P 5P
15P
3P
14P
4P
9P 6P
15P
18P 13P
22P
11P 18P 19P
22P 4P3P
3P 4P
CARD
POWER
20P
7P
19P
19P
7P
5P
8P
15P
TUNER PACK
MULTI-OUT B'D &
8P 100mm WIRE
SURROUND BACK AMP
HEAT SINK
INPUT & PROCESS B'D
PRE-OUT B'D
15P
15P
5P
5P
H/P B'D
3P 80mm WIRE
S/W B'D
TRANS
Function B'D
15P
15P
CPU B'D
DSP B'D
IN OUT B'D &
MIC B'D
PRE AMP B'D
C-VIDEO/S-VIDEO B'D
6CH INPUT B'D
REMOCON
3P 260mm WIRE
FRONT B'D
(N ONLY)
VIDEO B'D
COMPONENT
CDR CNT B'D
CONNECTION B'D
MAIN AMP B'D
D-VIDEO B'D
22P 180mm CARD CABLE
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
