242
AVR-2105/885 / AVC-1890
PARTS LIST OF EXPLODED VIEW (FOR JAPAN)
Ref. No. Part No. Part Name Remarks Q'ty New
00D 963 0157 007 MAIN P.W.B ASSY 1 *
12 SWITCH P.W.B ASSY
13 POWER SWITCH P.W.B ASSY
15 HEAD PHONE P.W.B ASSY
44 VIDEO CNT P.W.B ASSY
39 MAIN P.W.B ASSY
00D 963 0157 104 CPU,FRONT P.W.B ASSY 1 *
17 FRONT S-VIDEO P.W.B ASSY
18 V.AUX P.W.B ASSY
19 FRONT OPTICAL P.W.B ASSY
35 CDR-CNT P.W.B ASSY
21 FRONT P.W.B ASSY
31 CPU P.W.B ASSY
00D 963 0157 201 CNT,PRE-AMP P.W.B ASSY 1 *
43 VIDEO-PREOUT-CNT P.W.B ASSY
45 OUTLET P.W.B ASSY
54 2CH-AMP P.W.B ASSY
30 CNT P.W.B ASSY
40 PRE-AMP P.W.B ASSY
00D 963 0157 308 INPUT,VIDEO P.W.B ASSY 1 *
20 MIC P.W.B ASSY
37 VIDEO P.W.B ASSY
42 PRE-OUT P.W.B ASSY
34 INPUT P.W.B ASSY
00D 963 0155 407 DSP P.W.B ASSY 1 *
36 DSP P.W.B ASSY
00D 963 0157 405 D-VIDEO P.W.B ASSY 1 *
32 EXT-INPUT P.W.B ASSY
41 D-VIDEO P.W.B ASSY
1 00D 963 0152 206 WINDOW 1
2 00D 963 0152 507 INPUT KNOB 1
3 00D 963 0051 514 DENON BADGE 1
4 00D 963 0051 310 LED LENS 2
5 00D 963 015 2808 VOLUME KNOB 1
6 00D 963 0153 108 SELECT KNOB 1
7 00D 963 0150 305 FRONT PANEL 1
9 00D 963 0151 508 FRONT FRAME 1
10 00D 963 0137 807 STANDBY LENS 1
11 00D 963 0140 205 STANDBY BUTTON 1
14 00D 963 0139 902 POWER BUTTON 1
16 00D 963 0094 801 3KEY(A) BUTTON 2
22 00D 963 0137 205 CHASSIS 1
23 00D 963 0137 904 FOOT 4
24 00D 963 0051 103 CARD SPACER 2
25 00D 960 0003 301 PWB SUPPORTER 2
26 00D 960 0184 107 SUPPORTER BRACKET 1
27 00D 963 0044 602 P.C. SUPPORTER 2
28 00D 963 0092 609 TRANS BRACKET 1
! 29 00D 963 0094 908 POWER TRANS 1
38 00D 960 0184 000 SCREW BRACKET 4
46 00D 960 0184 204 HEAT SINK-B BRACKET 1
47 00D 960 0184 301 HEAT SINK-F BRACKET 1
48 - HEAT SINK 1
49 00D 963 0044 107 Transistor 2SB1560-Y Q102C, FL, FR, SL, SR 5
50 00D 963 0044 204 Transistor 2SD2390-Y Q101C, FL, FR, SL, SR 5
51 00D 963 0058 106 Transistor 2SD947F Q103C, 3FL, FR, SL, SR 5
52 00D 960 0187 900 POSISTOR 1
