Denon AVR-2105 Service Manual

237
AVR-2105/885 / AVC-1890
11 00D 963 0140 001 STANDBY BUTTON Black model 1
11 00D 963 0140 108 STANDBY BUTTON Silver model 1
11 00D 963 0140 205 STANDBY BUTTON Gold model 1
14 00D 963 0139 708 POWER BUTTON Black model 1
14 00D 963 0139 805 POWER BUTTON Silver model 1
14 00D 963 0139 902 POWER BUTTON Gold model 1
16 00D 963 0094 801 3KEY(A) BUTTON 4
22 00D 963 0137 205 CHASSIS 1
23 00D 963 0137 904 FOOT 4
24 00D 963 0051 103 CARD SPACER 2
25 00D 960 0003 301 PWB SUPPORTER 2
26 00D 960 0184 107 SUPPORTER BRACKET 1
27 00D 963 0044 602 P.C. SUPPORTER 2
28 00D 963 0092 609 TRANS BRACKET 1
! 29 00D 963 0154 709 POWER TRANS Europe, Asia 1
! 29 00D 96 30154 903 POWER TRANS Korea 1
33 00D 963 0145 608 TUNER,FM/AM Korea 1
33 00D 963 0145 705 TUNER,FM/AM Europe, Asia 1
38 00D 960 0184 000 BRACKET 4
46 00D 960 0184 204 HEAT SINK-B BRACKET 1
47 00D 960 0184 301 HEAT SINK-F BRACKET 1
48 - HEAT SINK 1
49 00D 963 0044 107 Transistor 2SB1560-Y Q102C, FL, FR, SL, SR 5
50 00D 963 0044 204 Transistor 2SD2390-Y Q101C, FL, FR, SL, SR 5
51 00D 963 0058 106 Transistor 2SD947F Q103C, 3FL, FR, SL, SR 5
52 00D 960 0187 900 POSISTOR 1
53 00D 963 0101 600 PWB BRACKET 4
55 00D 960 0192 403 STOPPER 1
! 56 00D 963 0109 806 CORD ASSY Europe, Asia 1
! 56 00D 963 0098 700 CORD ASSY Korea 1
57 00D 960 0183 807 TERMINAL 1
58 00D 963 0101 804 TRANS CUSHION 1
59 00D 960 0183 205 TOP CABINET Black model 1
59 00D 963 0117 102 TOP CABINET Silver model 1
59 00D 963 0055 510 TOP CABINET Gold model 1
60 00D 963 0150 703 BACK PANEL Europe, Asia 1
60 00D 963 0150 800 BACK PANEL Korea 1
61 00D 963 0120 306 SIDE BRACKET 1
63 - TAPE 1
64 00D 960 0235 205 FOOT CUSHION 4
65 00D 963 0161 608 BOTTOM BRACKET 1
★
00D 960 0155 301 CLAMP 5
★
00D 963 0161 404 CABLE,FLAT CARD 1.25MM 1
★
00D 963 0161 501 CABLE,FLAT CARD 1.25MM 1
★
- BUSHING 18
★
00D 963 0140 409 LICENCE LABEL 1
SCREWS
A 00D 963 0018 007 Screw (2S 3*8 ZNY/BH) 63
B 00D 960 0108 701 Screw (2S 3*10 DOT BK) 47
C 00D 960 9008 420 Screw (2S 3*8 WASHER) 4
D 00D 963 9004 054 Screw (2S 3*15 ZNY/BH) 3
E 00D 963 9004 025 Screw (3S 4*6 ZNY/BH) 6
F 00D 960 9008 417 Screw (3S 4*8 ZNY/BH) 4
G 00D 963 0018 104 Screw (2S 3*17 ZNY/BH) 1
H 00D 963 9006 175 Screw (2S 3*14 ZNY/HH) 21
J 00D 963 0048 307 Screw (2S 4*8 DOT BK) Black model 6
K 00D 963 9004 012 Screw (2S 4*8 DOT NI) Silver, Gold model 6
L 00D 963 9004 041 Screw (2S 3*5 ZNY/BH) 2
