Denon AVR-2105 Service Manual

43
AVR-2105/885 / AVC-1890
C136 00D 963 0161 307 Electrolytic 12000uF/63V *
C137 00D 963 0161 307 Electrolytic 12000uF/63V *
C138 00D 963 9006 379 Electrolytic 1uF/50V
C138A 00D 963 9003 097 Mylar film 0.1uF/250V
C141 00D 963 0021 900 Mylar film 0.047uF/100V
C142 00D 963 0021 900 Mylar film 0.047uF/100V
C143 00D 963 0021 900 Mylar film 0.047uF/100V
C144 00D 960 9007 201 Electrolytic 3300uF/35V
C145 00D 963 9003 123 Electrolytic 1000uF/35V
C146 00D 963 9006 379 Electrolytic 1uF/50V
C148 00D 963 9006 379 Electrolytic 1uF/50V
C150 00D 963 0021 900 Mylar film 0.047uF/100V
C151 00D 963 0021 900 Mylar film 0.047uF/100V
C152 00D 963 0021 900 Mylar film 0.047uF/100V
C153 00D 963 0021 104 Electrolytic 6800uF/16V
C154 00D 963 9006 308 Electrolytic 10uF/50V
C155 00D 963 0020 202 Ceramic 0.1uF/50V
C157 00D 963 9006 379 Electrolytic 1uF/50V
C158 00D 963 9003 136 Electrolytic 1000uF/25V
C159 00D 963 9006 379 Electrolytic 1uF/50V
C161 00D 963 9006 308 Electrolytic 10uF/50V
C171 00D 963 9005 312 Electrolytic 100uF/10V
C171A 00D 963 0020 202 Ceramic 0.1uF/50V
C171B 00D 963 0020 202 Ceramic 0.1uF/50V
C171C 00D 963 0020 202 Ceramic 0.1uF/50V
C171D 00D 963 0020 202 Ceramic 0.1uF/50V
C172 00D 963 9005 833 Electrolytic 220uF/6.3V
C173 00D 963 9005 833 Electrolytic 220uF/6.3V
C174 00D 963 9006 308 Electrolytic 10uF/50V
C175 00D 963 0149 507 Electrolytic 220uF/16V
C176 00D 963 9006 379 Electrolytic 1uF/50V
C177 00D 963 9006 379 Electrolytic 1uF/50V
C178 00D 963 0157 900 Electrolytic 470uF/63V *
C179 00D 963 9005 833 Electrolytic 220uF/6.3V
! C181 00D 963 9006 191 Ceramic 4700pF/250V(AC)
C182 00D 963 9006 311 Electrolytic 10uF/100V
C331 00D 963 9004 546 Ceramic 0.01uF/16V
C332 00D 963 9004 546 Ceramic 0.01uF/16V
C901H 00D 963 9004 533 Ceramic 0.001uF/50V
C902H 00D 963 9004 533 Ceramic 0.001uF/50V
C903H 00D 963 0020 202 Ceramic 0.1uF/50V
C904H 00D 960 9003 108 Ceramic 0.022uF/25V
C905H 00D 963 0020 202 Ceramic 0.1uF/50V
C906H 00D 963 9004 546 Ceramic 0.01uF/16V
OTHER PARTS GROUP
CB903 00D 963 0154 602 Beads inductor *
CB904 00D 963 0154 602 Beads inductor *
CN901 00D 963 0160 201 3P connector cord *
CN931A 00D 963 0148 809 2P connector cord
CN992 00D 963 0160 007 4P connector cord *
! CP101 00D 960 0118 908 AC cord connector base
CP102 00D 960 0123 304 2P connector base
CP103 00D 960 0128 901 3P connector base
CP104 00D 960 0128 804 6P connector base
CP105 00D 963 0149 109 2P connector base(BLACK)
