Denon AVR-2105 Service Manual

66
AVR-2105/885 / AVC-1890
C874SL 00D 963 9006 146 Ceramic chip 560pF/50V
C874SR 00D 963 9006 146 Ceramic chip 560pF/50V
C874SW 00D 963 9006 146 Ceramic chip 560pF/50V
C875C 00D 963 9005 778 Electrolytic 10uF/50V
C875FL 00D 963 9005 778 Electrolytic 10uF/50V
C875FR 00D 963 9005 778 Electrolytic 10uF/50V
C875SBL 00D 963 9005 778 Electrolytic 10uF/50V
C875SBR 00D 963 9005 778 Electrolytic 10uF/50V
C875SL 00D 963 9005 778 Electrolytic 10uF/50V
C875SR 00D 963 9005 778 Electrolytic 10uF/50V
C875SW 00D 963 9005 778 Electrolytic 10uF/50V
C876C 00D 960 9008 611 Mylar film 0.0033uF/100V
C876FL 00D 960 9008 611 Mylar film 0.0033uF/100V
C876FR 00D 960 9008 611 Mylar film 0.0033uF/100V
C876SBL 00D 960 9008 611 Mylar film 0.0033uF/100V
C876SBR 00D 960 9008 611 Mylar film 0.0033uF/100V
C876SL 00D 960 9008 611 Mylar film 0.0033uF/100V
C876SR 00D 960 9008 611 Mylar film 0.0033uF/100V
C876SW 00D 960 9008 611 Mylar film 0.0033uF/100V
C880C 00D 963 9005 778 Electrolytic 10uF/50V
C889 00D 963 9004 698 Ceramic chip 0.01uF/50V
C890 00D 963 9004 698 Ceramic chip 0.01uF/50V
C891 00D 963 9004 698 Ceramic chip 0.01uF/50V
C893 00D 963 9005 749 Electrolytic 1uF/50V
C894 00D 963 9004 698 Ceramic chip 0.01uF/50V
C896 00D 963 9005 927 Electrolytic 0.1uF/50V
C902 00D 963 9005 901 Electrolytic 470uF/10V
C907 00D 963 9005 312 Electrolytic 100uF/10V
C912 00D 963 9004 698 Ceramic chip 0.01uF/50V
C913 00D 963 9004 698 Ceramic chip 0.01uF/50V
C920 00D 963 9004 902 Ceramic chip 18pF/50V
OTHER PARTS GROUP
CB801 00D 963 0050 502 Chip emifil
CB802 00D 963 0050 502 Chip emifil
CB803 00D 963 0050 502 Chip emifil
CB804 00D 963 0050 502 Chip emifil
CB805 00D 963 0050 502 Chip emifil
CB806 00D 963 0050 502 Chip emifil
CB808 00D 963 0050 502 Chip emifil
CB810 00D 963 0050 502 Chip emifil
CN801 00D 963 0086 301 18P connector socket (TUC-P)
CN802 00D 963 0086 204 19P connector socket (TUC-P)
CN803 00D 960 0239 900 13P connector socket (TUC-P)
JACK801 00D 963 0052 500 1P pin jack
L801 00D 963 0050 803 Inductor 4.7uH
L802 00D 963 0050 803 Inductor 4.7uH
L803 00D 963 0050 803 Inductor 4.7uH
L804 00D 963 0050 803 Inductor 4.7uH
L805 00D 963 0050 900 Inductor 2.2uH
R831 00D 963 0120 908 Beads inductor
R832 00D 963 0120 908 Beads inductor
R833 00D 963 0120 908 Beads inductor
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
