Denon AVR-2105 Service Manual

82
AVR-2105/885 / AVC-1890
C506C 00D 963 9005 312 Electrolytic 100uF/10V
C506FL 00D 963 9005 312 Electrolytic 100uF/10V
C506FR 00D 963 9005 312 Electrolytic 100uF/10V
C506SBL 00D 963 9005 312 Electrolytic 100uF/10V
C506SBR 00D 963 9005 312 Electrolytic 100uF/10V
C506SL 00D 963 9005 312 Electrolytic 100uF/10V
C506SR 00D 963 9005 312 Electrolytic 100uF/10V
C507C 00D 963 9003 194 Mylar film 0.0022uF/100V
C507FL 00D 963 9003 194 Mylar film 0.0022uF/100V
C507FR 00D 963 9003 194 Mylar film 0.0022uF/100V
C507SBL 00D 963 9003 194 Mylar film 0.0022uF/100V
C507SBR 00D 963 9003 194 Mylar film 0.0022uF/100V
C507SL 00D 963 9003 194 Mylar film 0.0022uF/100V
C507SR 00D 963 9003 194 Mylar film 0.0022uF/100V
C508C 00D 963 9006 382 Electrolytic 22uF/25V
C508FL 00D 963 9006 382 Electrolytic 22uF/25V
C508FR 00D 963 9006 382 Electrolytic 22uF/25V
C508SBL 00D 963 9006 382 Electrolytic 22uF/25V
C551 00D 963 9006 405 Electrolytic 2.2uF/50V
C551M 00D 963 0161 200 Electrolytic 10uF/25V *
C551S 00D 963 9004 562 Ceramic 0.047uF/50V
C552 00D 963 9006 366 Electrolytic 0.1uF/50V
C553 00D 963 9006 366 Electrolytic 0.1uF/50V
C554 00D 963 9006 366 Electrolytic 0.1uF/50V
C555 00D 963 9004 546 Ceramic 0.01uF/16V
C556 00D 963 9004 546 Ceramic 0.01uF/16V
C557 00D 963 9006 308 Electrolytic 10uF/50V
C558 00D 963 9006 366 Electrolytic 0.1uF/50V
C559 00D 963 0145 006 Mylar film 0.047uF/50V
C561 00D 963 0145 006 Mylar film 0.047uF/50V
C562 00D 963 9004 546 Ceramic 0.01uF/16V
C563 00D 963 9004 546 Ceramic 0.01uF/16V
C564 00D 960 0133 501 Electrolytic 2200uF/16V
OTHER PARTS GROUP
CN1153 00D 963 0097 303 15P connector socket (TUC-P)
CN501 00D 963 0085 603 5P connector socket (TUC-P)
CN502 00D 963 0086 602 12P connector socket (TUC-P)
CN503 00D 963 0086 505 7P connector socket (TUC-P)
CN504 00D 963 0085 506 9P connector socket (TUC-P)
CN505 00D 963 0086 505 7P connector socket (TUC-P)
CN506 00D 963 0060 903 15P connector base
CN506T 00D 963 0159 704 15P connector cord *
CN510 00D 963 0160 405 5P connector cord *
CN551 00D 963 0097 206 8P connector socket (TUC-P)
CN552 00D 963 0086 204 19P connector socket (TUC-P)
CN553 00D 963 0097 206 8P connector socket (TUC-P)
CN554 00D 963 0160 609 15P connector cord *
CN555 00D 963 0086 709 11P connector socket (TUC-P)
CN556 00D 963 0159 403 15P connector cord *
CN557 00D 963 0086 709 11P connector socket (TUC-P)
CN560 00D 963 0110 701 14P connector socket (TUC-P)
CN992 00D 960 0217 553 4P connector base
CP1154 00D 963 0097 507 15P connector base (TUC-P)
CP508 00D 963 0068 303 9P connector base
CP509 00D 963 0060 505 7P connector base
CP510 00D 963 0066 101 5P connector base
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
