Denon AVR-2105 Service Manual

81
AVR-2105/885 / AVC-1890
VR106 00D 963 0105 208 Semi fixed resistor 1 kohm
VR107 00D 963 0105 208 Semi fixed resistor 1 kohm
CAPACITORS GROUP
C101SBL 00D 963 9006 450 Electrolytic 47uF/50V
C101SBR 00D 963 9006 450 Electrolytic 47uF/50V
C102SBL 00D 963 9006 308 Electrolytic 10uF/50V
C102SBR 00D 963 9006 308 Electrolytic 10uF/50V
C103SBL 00D 963 9003 084 Ceramic 100pF/500V
C103SBR 00D 963 9003 084 Ceramic 100pF/500V
C104SBL 00D 963 9003 084 Ceramic 100pF/500V
C104SBR 00D 963 9003 084 Ceramic 100pF/500V
C105SBL 00D 963 9008 640 Mylar film 0.022uF/100V
C105SBR 00D 963 9008 640 Mylar film 0.022uF/100V
C107SBL 00D 963 9003 097 Mylar film 0.1uF/250V
C107SBR 00D 963 9003 097 Mylar film 0.1uF/250V
C201PC 00D 963 9004 575 Ceramic chip 100pF/50V
C201PFL 00D 963 9004 575 Ceramic chip 100pF/50V
C201PFR 00D 963 9004 575 Ceramic chip 100pF/50V
C201PSL 00D 963 9004 575 Ceramic chip 100pF/50V
C201PSR 00D 963 9004 575 Ceramic chip 100pF/50V
C201PSW 00D 963 9004 575 Ceramic chip 100pF/50V
C258 00D 963 0021 104 Electrolytic 6800uF/16V
C501C 00D 963 9006 382 Electrolytic 22uF/25V
C501FL 00D 963 9006 382 Electrolytic 22uF/25V
C501FR 00D 963 9006 382 Electrolytic 22uF/25V
C501SBL 00D 963 9006 382 Electrolytic 22uF/25V
C501SBR 00D 963 9006 382 Electrolytic 22uF/25V
C501SL 00D 963 9006 382 Electrolytic 22uF/25V
C501SR 00D 963 9006 382 Electrolytic 22uF/25V
C502C 00D 963 9006 308 Electrolytic 10uF/50V
C502FL 00D 963 9006 308 Electrolytic 10uF/50V
C502FR 00D 963 9006 308 Electrolytic 10uF/50V
C502SBL 00D 963 9006 308 Electrolytic 10uF/50V
C502SBR 00D 963 9006 308 Electrolytic 10uF/50V
C502SL 00D 963 9006 308 Electrolytic 10uF/50V
C502SR 00D 963 9006 308 Electrolytic 10uF/50V
C503C 00D 963 9003 165 Ceramic 220pF/500V
C503FL 00D 963 9003 165 Ceramic 220pF/500V
C503FR 00D 963 9003 165 Ceramic 220pF/500V
C503SBL 00D 963 9003 165 Ceramic 220pF/500V
C503SBR 00D 963 9003 165 Ceramic 220pF/500V
C503SL 00D 963 9003 165 Ceramic 220pF/500V
C503SR 00D 963 9003 165 Ceramic 220pF/500V
C504C 00D 963 0157 502 Ceramic 220pF/50V *
C504FL 00D 963 0157 502 Ceramic 220pF/50V *
C504FR 00D 963 0157 502 Ceramic 220pF/50V *
C504SBL 00D 963 0157 502 Ceramic 220pF/50V *
C504SBR 00D 963 0157 502 Ceramic 220pF/50V *
C504SL 00D 963 0157 502 Ceramic 220pF/50V *
C504SR 00D 963 0157 502 Ceramic 220pF/50V *
C505C 00D 963 9003 181 Ceramic 33pF/500V
C505FL 00D 963 9003 181 Ceramic 33pF/500V
C505FR 00D 963 9003 181 Ceramic 33pF/500V
C505SBL 00D 963 9003 181 Ceramic 33pF/500V
C505SBR 00D 963 9003 181 Ceramic 33pF/500V
C505SL 00D 963 9003 181 Ceramic 33pF/500V
C505SR 00D 963 9003 181 Ceramic 33pF/500V
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
