Denon AVR-2105 Service Manual

80
AVR-2105/885 / AVC-1890
D559 00D 963 0020 309 Diode 1SS133T
D560 00D 963 0020 309 Diode 1SS133T
D561 00D 963 0020 309 Diode 1SS133T
D562 00D 963 0058 407 Diode IN4007
D563 00D 963 0058 407 Diode IN4007
D564 00D 963 0020 309 Diode 1SS133T
D565 00D 960 0095 500 Zener diode MTZJ5.1B
D566 00D 963 0020 309 Diode 1SS133T
D567 00D 963 0020 309 Diode 1SS133T
D568 00D 963 0020 309 Diode 1SS133T
D568C 00D 960 0197 000 Diode KDS160
D569 00D 963 0020 309 Diode 1SS133T
D569C 00D 960 0197 000 Diode KDS160
D570C 00D 960 0197 000 Diode KDS160
D573 00D 963 0058 407 Diode IN4007
D574 00D 963 0058 407 Diode IN4007
D575 00D 963 0058 407 Diode IN4007
RESISTORS GROUP
R104SBL 00D 963 9006 285 Metal oxide 5.6 kohm 1W
R104SBR 00D 963 9006 285 Metal oxide 5.6 kohm 1W
R105SBL 00D 963 9006 285 Metal oxide 5.6 kohm 1W
R105SBR 00D 963 9006 285 Metal oxide 5.6 kohm 1W
R106SBL 00D 963 0047 900 Metal film 4.7 kohm 1W
R106SBR 00D 963 0047 900 Metal film 4.7 kohm 1W
R107SBL 00D 963 0047 900 Metal film 4.7 kohm 1W
R107SBR 00D 963 0047 900 Metal film 4.7 kohm 1W
R108SBL 00D 963 9006 269 Metal oxide 0.22 ohm 1W
R108SBR 00D 963 9006 269 Metal oxide 0.22 ohm 1W
R109SBL 00D 963 9006 269 Metal oxide 0.22 ohm 1W
R109SBR 00D 963 9006 269 Metal oxide 0.22 ohm 1W
R110SBL 00D 963 9006 269 Metal oxide 0.22 ohm 1W
R110SBR 00D 963 9006 269 Metal oxide 0.22 ohm 1W
R111SBL 00D 963 9006 269 Metal oxide 0.22 ohm 1W
R111SBR 00D 963 9006 269 Metal oxide 0.22 ohm 1W
R118SBL 00D 963 9006 256 Metal oxide 10 ohm 1W
R118SBR 00D 963 9006 256 Metal oxide 10 ohm 1W
R119SBL 00D 963 9006 256 Metal oxide 10 ohm 1W
R119SBR 00D 963 9006 256 Metal oxide 10 ohm 1W
R509C 00D 960 9005 902 Metal film 1.2 kohm 1/4W
R509FL 00D 960 9005 902 Metal film 1.2 kohm 1/4W
R509FR 00D 960 9005 902 Metal film 1.2 kohm 1/4W
R509SBL 00D 960 9005 902 Metal film 1.2 kohm 1/4W
R509SBR 00D 960 9005 902 Metal film 1.2 kohm 1/4W
R509SL 00D 960 9005 902 Metal film 1.2 kohm 1/4W
R509SR 00D 960 9005 902 Metal film 1.2 kohm 1/4W
R511C 00D 960 9004 301 Metal film 47 ohm 1/4W
R511FL 00D 960 9004 301 Metal film 47 ohm 1/4W
R511FR 00D 960 9004 301 Metal film 47 ohm 1/4W
R511SBL 00D 960 9004 301 Metal film 47 ohm 1/4W
R511SBR 00D 960 9004 301 Metal film 47 ohm 1/4W
R511SL 00D 960 9004 301 Metal film 47 ohm 1/4W
R511SR 00D 960 9004 301 Metal film 47 ohm 1/4W
R559 00D 963 9005 642 Metal film 1.2 kohm 1W
R565 00D 963 9005 642 Metal film 1.2 kohm 1W
R570 00D 963 9005 642 Metal film 1.2 kohm 1W
R575 00D 963 9006 269 Metal oxide 0.22 ohm 1W
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
